pvc gypsum ceiling board building materials

Specifications

PVC Gypsum Ceiling Board
1.prime quality and Competitive Price
2.Heat & sound insulation
3.High Strength
4.supplyingT-gridsy





pvc gypsum ceiling board



1) Material: paper-faced gypsum board PVC facing + aluminum foil backing







2) Thickness: 7.5mm, 8.0mm, 9.0mm, 12.0mm,







3) Sizes:595 x 595mm, 600mmX600mm, 603 x 603mm, 595*1195mm, 600*1200mm, 603mm x 1212mm,







4) Size tolerance: Length <+/-1.0mm, width < +/-1.0mm, thickness <+/-0.5mm







5) Weight: 7.5mm=5.7kg/sqm, 8.0mm=5.9kg/sqm, 8.5mm=6.2kg/sqm, 9mm=6.8kg/sqm, 9.5mm=7.1kg/sqm, 12mm=9.2kg/sqm, 12.5mm=9.5kg/sqm







6) Strength: >100N







7) Characters: Non-flammable B1, in accordance with Chinese standard GB8624-1997







8) Installation: Match with ceiling T-bar Packing: Export carton(6pcs,8pcs or 10 pcs per carton with film)











size	595*595	600*600	603*603	605*605
Thickness	7.5mm-12mm
Feature	Normal design	special paint
packing	Every eight pieces into one carton,then into container
Description	one side aluminum foil bacl,the other side different designs
Features:
1)Environmental friendly
2)Non-combustible
3)High strength
4)Heat & sound insulation
5)Easy to install and fix





Thickenss canbe from 0.2-0.5mm.
