Directly Face Magnesium Oxide Boards

Directly Face Magnesium Oxide Boards thumbnail-1
Directly Face Magnesium Oxide Boards photo-1
US$ 3 - 10 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
DYBM
Model Number:
MG-A
Contact Supplier Request Quote Chat Now
Jinzhou Dongya Building Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name DYBM
Model Number MG-A

Specifications

Mgo board without foam for wall construction
1.Material:Mgo board
2.Mgo channel thickness is 5mm

mgo fireproof board



Composition:

magnesium oxide, magnesium chloride,   fiberglass mesh,  perlite,  saw dust



Main features :

1.Fireproof: it reach the standard of GB8624-Class A.





2.Waterproof: it can keep its shape and character after soaking in water for a few days.



3.Soundproof and heat preservation: the character of soundproof and heat preservation achieves good results and meets the standard of our state.





4.No asbestos: it does not contain any asbestos.





5.Environmental protection: it does not pollute the environment during the producing process and does not release poisonous material.



6.Affinity good: spray or paste surface ,it is very solid and without hollowing.



7.Easy to install: you can process it in the way of sawing , planing, drilling, nailing and cutting etc.



8.Saving energy: using a lot of industrial waste, it can save natural sources such as wood etc.





9.It is renewing product of plywood, MDF board, shaving board, paper gypsum board etc.



specifications



1220X2440, 1200x2500/2600/3000, 900X1800, 900X2400 (mm) etc.



Thickness: 3-40(mm)





Note: Other sizes can be ordered according to customer’s requests.



test results:





Test item

Technical requirement

Test results

Results

Density (t/m3)



1.05

Qualified

Bending strength(Mpa)

≥10

16.0

Qualified

Impact strength

(KJ/m2)

≥2.5

10

Qualified

Moisture absorption

No moisture

No moisture

Qualified

Water content  (%)

≤8

3.7

Qualified

Contraction rate when heated  (%)

≤0.3

0.1

Qualified

Expansion when put into water  (%)

≤0.6

0.23

Qualified

Crisp coefficient

≥0.7

1.3

Qualified

Warp when heated (‰)

≤3

0.12

Qualified

Put out of nails

e<6

6<e<10

e >10

35

Qualified

≥25

≥20

≥15



Main usage:



Magnesium oxide board have been used primarily as fireproof materials for walls and ceilings in office buildings, apartment complexes, residential constructions, hotels, theatres, restaurants, railway stations, airports, scientific research institutions, schools, hospitals, and stadiums. Some patterned products have been used as decorative boards.

It also can be used as an interlayer for building, movable partitions, sound-absorbing structures, sound insulation structures, heat insulation and preservation structures, sign boards, fireproof partition walls, low fencing partitions, fireproof pipeline, fireproof doors, cornice baffle boards, public restroom dividers, baseboards, truck cabinets and billboards etc.

Directly face Magnesium Oxide BoardsDirectly face Magnesium Oxide BoardsDirectly face Magnesium Oxide Boards
