Home > Construction & Decoration > Decoration Materials > Cement Board > Wall Panel 100% Non Asbestos Fiber Cement Board

Wall Panel 100% Non Asbestos Fiber Cement Board

Wall Panel 100% Non Asbestos Fiber Cement Board thumbnail-1
Wall Panel 100% Non Asbestos Fiber Cement Board photo-1
US$ 3 - 10 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
DYBM
Model Number:
fiber cement board
Contact Supplier Request Quote Chat Now
Jinzhou Dongya Building Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name DYBM
Model Number fiber cement board
Feature Perforated
Type Non-Asbestos Fiber Cement Boards

Specifications

fiber cement board
1.size:1200 x 2400mm,1220 x 2440mm
2.thickness:5mm to 20mm
3.density: 1.2-1.5g/cm3

fiber cement board

Specifications:

1) 100% asbestos free
2) Non-combustible:GB8624, CLASS A
3) Moisture resistant
4) Excellent impact resistance

fiber cement board is a composite material made of sand, cement and cellulose fibers.

fiber cement board is manufactured in a sheet form and is used not only as cladding but also commonly used as an eave lining and as a tile underlay on decks and in bathrooms.

Also the most use is wall partition





Size

Thickness

3.5mm~25mm

Widths

1220 mm

Lengths

2440 mm



Note: All metric / standard boards come with cutting square edges. Recessed edges may be available upon request. Other sizes are also available and can be produced to special order.



fiber cement board description:

Raw Materials: Cement, Quartz Sand, Fiber
Basic Color: Gray, invory , off-white, pure white
Density:≥1.25g/cm3
Moisture Content: ≤10%
Water Absorbing Capacity: ≤40%
Thermal Conductivity: Average≤0.20W/MK
Bending Strength: Transverse≥11.0N/mm3 Vertical≥8.5N/mm3

Size:1220mmx2440mm,1200mmx2400mm,915mmx1830mm,1220mmx3660mm

Thickness:3mm---24mm



Manufacturing Tolerances

Length tolerance

+/- 5mm

Width tolerance

+/- 5mm

Thickness tolerance

+/- 0.3mm

Diagonal tolerance

+/- 5mm

Physical properties

Item

Index

Unit

Density

≥

g/cm3

Thermal Conductivity

≤0.25

W/(m.k)

Water Absorption

≤40

%

Water Contain

≤10

%

Moisture Movement

≤0.25

%

Heat Shrinage

≤0.5

%

Non-combustibility

GB 8624 Class A1

/

Bending

Strength

Oven dry

Cross

≥12.0

Mpa

Parallel

≥9.0

Mpa

REMARK;Please contact our us if you need more technical index.



SAFETY CPABILITY

Item

Index



Asbestos Including

100% asbestos free

Safe for application

Radioactive

<1.0 IRa

Safe for application

<1.0 Ir

Safe for application

Non-combustibility

A1

The highest grade



KEY BENEFITS

  • Fire Resistant: ‘Class A’ (0 Flame / 0 Smoke)
  • Noncombustible: (10-minute duration)
  • Mold/Fungus Resistant: Does not support mold/fungus growth
  • Moisture Resistant: Resistant to weather, freeze/thaw & standing water
  • Termite/Vermin Resistant: Provides no food value to insects/vermin
  • Impact & Abuse Resistant: Made from durable Portland Cement
  • Acoustic Performance: Has a density of 77lbs/ft3
  • Workability: Installs quickly using standard carpentry tools and equipment
  • Dimensionally Stable: Exhibits excellent resistance to dimensional changes when exposed to variations in temperature & moisture
  • Environmentally Friendly: Composed of 28% post-industrial wood content, contains no added HCFC’s or VOC’s, no added formaldehyde or asbestos, reduces materials on the job

A few reasons why our boards benefits:

  • Up to 76% fewer seams
  • Never requires painting
  • 4 times more insulating power
  • 45% more noise reduction
  • Guaranteed to let your home breathe
  • 300% more impact protection
  • Improved energy-efficiency
  • Seal out dust and dirt from outside
  • Reduce noise from the outside
  • Easy to clean
  • Enhanced security
  • Resists damage from cold, windy climates
  • Resists damage from wet, humid climates
  • Resists flame.
  • Resists damage from flying debris
  • Resists insect damage.
  • Resists cracking.



APPLICATIONS

  • Excellent for interior & exterior walls, partitions, curtain walls, fire-stops & more
  • Great substrate for exterior finish materials
  • Abuse resistant

wall panel 100% non asbestos fiber cement boardwall panel 100% non asbestos fiber cement boardwall panel 100% non asbestos fiber cement boardwall panel 100% non asbestos fiber cement boardwall panel 100% non asbestos fiber cement boardwall panel 100% non asbestos fiber cement board
