Marine Navigation Specialist Azimuth Circles
- Ningbo
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | SH | |
| Model Number | GFC | Part | Other, Azimuth circles |
Product Description
Specifications
1>GFC Series Azimuth Circle for Magnetic Compass2>Model: GFC-165,GFC-190
3>Reasonable Price
MAIN TECHNICAL DATA:
a) Temperature range -30°C~+60°C
b) Deviation between the sight mark line on the prism box and the graduation zero line ≤0.06mm
c) Deviation between the central line of the sight seam and the sight mark line ≤0.5mm
d) Deviation between the sight seam and the sight line <12' (the left and right) <1° (in front and behind)
e) Material high quality non-magnetic material
f) Azimuth circle can rotate easily on the compass and shouldn't produce a sidewise motion leading a reading error of more than 2°
OVERALL DIMENSION:
Type | Internal Diameter | Outer Diameter | Weight (kg) |
GFC-165 | Ø226 | Ø239 | 1.6 |
GFC-190 | Ø247 | Ø260 | 1.7 |
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
| |
|
|
| |
|
|
|
|
