Home > Products > 23 Rigging & Deck Items > Marine Wholesale Boat Pilot Ladder
Marine Wholesale Boat Pilot Ladder
- Ningbo
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | J-Marine | |
| Part | Other |
Product Description
Specifications
1>Pilot Embarkation Rope Ladder Rubber step2>Made Hign quality rubber with steel plate insert
3>525*115*28mm
PILOT LADDERS IMPA:232001-232002
1. Equipped in the embarking place of the life raft and boat, for pilots to board and leave the vessels.
2. In accordance with the 2000 Amendments to SOLAS 1974 and LSA.
3. The lowest 4 steps are rubber plates with steel lining; The count-down fifth plate is spreader step, and there are 8 short boards between two neighboring spreader steps; The distance between two neighboring steps :310 ± 5 mm.
Name | Size (mm) | Orifice | Material | |
Short Board | Long Board | |||
Pilot’s Rope Ladder | 525×115×28 (flat board) | 1800×115×28 | Φ25mm | willow |
525×115×(30~38) 525×115×(30~60) (slotting board) | ||||
Rope Ladder | 525×115×28 (flat board) | 1800×115×28 | ||
525×115×(30~38) 525×115×(30~60) (slotting b | ||||
