Alarm System Baggage Screen Machine,airport Baggage Inspection System

FEATURE:

1. Alarm by sounds & light::Alarm by sounds and light when conform to condition.

2. Network interface:Could be connect local area network and support multi-terminal check baggage at same times

3. Safety ray:Transmit ray under automatic control, avoids the miss.

4. Turn off by a key control:Turn off the machine only need one step:revolves the key. The equipment automatic security close-down, does not need complex many steps, is simpler.

5. Eagle-eye:Could be expediently observing enlargement area.

6. Estimate malfunction by self:Automatic estimate malfunction and prompt message, helpful for the maintenance.

TECHNICAL DATA:

Tunnel Size:                    1000(W)×1000(H)mm

Conveyor Speed:                 0.22 m/s

Conveyor Max Load:              200 kg

Single inspection dosage           < 1µGy

Wire Resolution:                 0.1mm metal line

Steel Penetration:                 30MM armor plate

Film Safety:                     For ISO 1600

Maximum leakage radiation        <0.3µGY/H

X-RAY GENERATOR:

Orientation:                        Vertically Upward

Tube Current:                       0.4~1.2MA(adjustable)

Anode Voltage:                      100~160 KV(adjustable)

Angle:                             80°

Generator cooling/working periods       Sealed oil bath with forced air/100%

IMAGE PERFORMANCE SYSTEM:

X-ray Sensor:                      L Type Photo-Diode array detector 12bit.

Monitor:                          High resolution 17inch color LCD display.

Color Quality:                     24 Bit real colors.

Edge Enhancement:                 Object contour edge is more distinct.

Super Image Enhancement:           Image detail is more distinct.

High penetrate strength display:       Increase brightness of dark area in image to display object which is behind high absorptivity mass distinctly.

Low Penetrate strength Display:       increase contrast of low absorptivity mass (easy to penetrate) to display it distinctly.

Magnifier:                          Function of partial enlargement

Brightness/Dimming:                  Increase brightness of image/decrease brightness of image.

Image recurrence:              Display previous twenty image and process any one of them.

Image restoration:              Restore image to initial status at the time of stopping conveyor

Image storing:                 Real Time store any image and process it in operation status.

MULTI-ENERGY FUNCTION:

Multi-energy color:            Display organic material for orange, display inorganic material for blue, and display mixture for green.

High energy / low energy: switch to display two energy type, high energy stands for metal etc. low energy stands for nonmetallic.

Auxiliay function for drugs & explosives: Help to detect such dangerous material as drugs& explosives etc.

Audible & visible alarm:  Give sound and visible signal when conforming to condition.

ETHERNET TCP/IP FUNCTION

OPERATING ENVIRONMENT:

Storage Temperature:             -20ºC to 60ºC

Operating Temperature:           0ºC to 45ºC

Relative Humidity:               20 to 95% non-condensing

System Power:                  220 VAC (±10%) 50±3HZ

Power wastage:                1.5 KW (Max)

Noise:                        <65DB

we takes strong ploywooden case

shipment can takes of By sea

our sales team can give feedback within 12 hours after receive your inquiry

  we are a professional x ray baggage scanner machine manufacture

  we accept OEM and ODM service
