Features:
Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality
Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.
Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it'll be quiet. (Optional)
A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown automaticly ,reduce equipment failure.
Environmental-friendly Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.
Product certification:
Strict quality internal control , double-check principles of engineering and production
Safeguard measures for machine parts
Through the testing by Ministry of public security and police use electronic product quality testing center
Through the EU CE certification
Through the ISO9001 quality management system certification
Through the ISO14001 environmental management system certification
Through the GB/T28001 occupation health and safety management system certification
Through thes provincial Environmental Protection Department of radiation safety certification
Through the provincial occupation health inspection center detection of radiation
Through the the people's Republic of China State Bureau of copyright of computer software copyright registration certificate
Double soft certification
Image Processing System | |
X-ray sensor | L-shaped photodiode array detector (single energy), 12bit depth |
Monitor | high resolution 19 inch LCD BenQ monitor |
Color image display | 24-bit true color display |
Edge Enhancement | the outline of objects will be more clear |
Super Image Enhancement | the details of the image are more clear |
High penetration display | improve image contrast in bright areas, so the easy penetrating area will be more clear |
Low penetration display | improve image contrast in dark areas, so the difficult penetrating area will be more clear |
Magnifier local | amplification function |
Brighten / darken | Increase / decrease image brightness |
Image pull back / front pull | Show the top 20 images, and the current image can be any image processing |
Image Restoration | Restored to its original state |
Image Storage | Real-time save any image, any image can be processed arbitrarily ,continuous work to save |
Technical standards | Technical parameters |
By size | 500(W)×300(H)mm |
Conveyor speed | Hour detection 600ps / h toy shoes products 0.22m/s |
Load | 100 kg |
Resolution | Ø0.0787 mm |
Conveyor height from the ground | 700mm |
Penetration | ≥8mm |
Monitor | BenQ 19in LCD monitor |
Storage | 500G hard drive to save any image in real time, can store more than 100,000 |
Noise | ≤55dB(A) |
Operating system | windowsXP |
Single check dose | One-time inspection of the X-ray light source irradiation amount ≤ 1.22uGy |
Leaking radiation dose rate | Away from any device outer surface of 5cm, the ray irradiation leak rate should |
Dimensions | (L) 1750mm (W)730mm(H)1200mm |
NW / GW | 280 kg / 350 kg |
Application:
Designed for small mail parcel security check, primarily serves the post Express Logistics Center of small parcel safety testing centers.
