Help CenterLong Warranty Baggage x Ray Inspection Machine. Luggage Scanner Machines
Related Products
-
LCD Accord 650 mm * 500mm X Ray Baggage Scanning Machine for Super Market SecurityUS$ 11,300 - 12,800MOQ: 1 Set -
Hot Selling X-ray Baggage Scanning EquipmentUS$ 9,850 - 12,000MOQ: 1 Set
-
Hot Selling X-ray Baggage Scanning MachineUS$ 9,850 - 12,000MOQ: 1 Set
-
VX5030C Small Tunnel X-ray Baggage Scanner Best PriceUS$ 10,000 - 12,000MOQ: 1 Set
-
VX5030 Small Tunnel Airport X-ray Screening MachineUS$ 10,000 - 12,000MOQ: 1 Set
FEATURE:
Alarm by sounds & light::Alarm by sounds and light when conform to condition.
Network interface:Could be connect local area network and support multi-terminal check baggage at same times
Safety ray:Transmit ray under automatic control, avoids the miss
Turn off by a key control:Turn off the machine only need one step:revolves the key. The equipment automatic security close-down, does not need complex many steps, is simpler.
Eagle-eye:Could be expediently observing enlargement area.
Estimate malfunction by self:Automatic estimate malfunction and prompt message, helpful for the maintenance.
TECHNICAL DATA:
Tunnel Size: 800(W)×650(H)mm
Conveyor Speed: 0.22 m/s
Conveyor Max Load: 150 kg
Single inspection dosage: < 1.5µGy
Wire Resolution: 0.1mm metal line
Steel Penetration: 30MM armor plate
Film Safety: For ISO 1600
Maximum leakage radiation: <0.3µGY/H
X-RAY GENERATOR:
Orientation: Vertically Upward
Tube Current: 0.4~1.2MA(adjustable)
Anode Voltage: 100~160 KV(adjustable)
Angle: 80°
Generator cooling/working periods: Sealed oil bath with forced air/100%
Image performance system:
X-ray sensor: l type photo-diode array detector, 12bit
Monitor: high resolution 17inch color lcd display
Color quality: 24 bit real colors
Edge enhancement: object contour edge is more distinct
Super image enhancement: image detail is more distinct
High penetrate strength display: increase brightness of dark area in image to display object which is behind high absorbtivity mass distinctly
Low penetrate strength display: increase contrast of low absorbtivity mass (easy to penetrate) to display it distinctly
Magnifier: function of partial enlargement
Brightening/dimming: increase brightness of image/decrease brightness of image
Image recurrence: display previous twenty images and process any one of them
Image restoration: restore image to initial status at the time of stopping conveyor
Image storing: real time store any image and process it in operation status
Multi-energy function:
Multi-energy color: display organic material for orange, display inorganic material for blue, and display mixture for green
High energy/low energy: switch to display two energy type, high energy stands for metal etc., low energy stands for nonmetallic
Auxiliary function for drugs & explosives: help to detect such dangerous material as drugs & explosives etc.
Audible & visible alarm: give sound and visible signal when conforming to condition
OPERATING ENVIRONMENT:
Storage Temperature: -20ºC to 60ºC
Operating Temperature: 0ºC to 45ºC
Relative Humidity: 20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.2 KW (Max)
Noise: <65DB
We takes strong plywooden case
shipment can be By sea.
Our sales team can give feedback within 12 hours after receive your inquiry
