x-ray machine system manufacturer.xray baggage inspection machine

FOB Price

US$ 9,850 - 12,000 / Set

1 Set(Min. Order)

Port shenzhen or guangzhou
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	vfinder
Model Number	VX5030c

Packaging Details

strong plywood case

Product Description

x-ray machine system manufacturer. xray baggage inspection machine

Product Description

Advantages

1. With equipment to save electricity

2. Famous brand spare parts:

(1). Spellman brand generator from the USA

(2). Hamamatsu brand detector from Japan

(3). Interroll brand Roller from German

3. Protective cover on lead curtain to avoid lead pollution

4. Sound and light alarm

5. Local network supported

Features

Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality

Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.

Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it'll be quiet. (Optional)

A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown automaticly ,reduce equipment failure.

Environmental-friendly Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.

Dynamic screen switching: when it is stationary screen it can be switched and when it is dynamic it also can switch freely.

Product Certification

Strict quality internal control , double-check principles of engineering and production

Safeguard measures for machine parts

Through the testing by Ministry of public security and police use electronic product quality testing center

Through the EU CE certification

Through the ISO9001 quality management system certification

Through the ISO14001 environmental management system certification

Through the GB/T28001 occupation health and safety management system certification

Through thes provincial Environmental Protection Department of radiation safety certification

Through the provincial occupation health inspection center detection of radiation

Through the the people's Republic of China State Bureau of copyright of computer software copyright registration certificate

Double soft certification

X-ray Generator
Ray Beam direction	Bottom-illuminated
Tube current	0.4~0.5mA(adjustable)
Tube voltage	100-160 kV(adjustable)
Ray beam divergence angle	60°
The cooling / work cycle	Sealed oil cooling / 100%
Image Processing System
X-ray sensor	L-shaped photodiode array detector (C), 24bit depth
Monitor	high resolution 19 inch LCD SamSung monitor
Color image display	24-bit true color display
Edge Enhancement	the outline of objects will be more clear
Super Image Enhancement	the details of the image are more clear
High penetration display	improve image contrast in bright areas, so the easy penetrating area will be more clear
Low penetration display	improve image contrast in dark areas, so the difficult penetrating area will be more clear
Magnifier	local amplification function
Brighten / darken	Increase/ decrease image brightness
Image pull back / front pull	Show the top 20 images, and the current image can be any image processing
Image Restoration	Restored to its original state
Image Storage	Real-time save any image, any image can be processed arbitrarily ,continuous work to save
Environmental conditions
Operating temperature / humidity	0℃~45℃/20%~95% (No condensation)
Storage temperature / humidity	-20℃~60℃/20%~95% (No condensation)
Operating Voltage	220VAC(±10%) 50±3Hz
Power consumption	1.0KW(maximum)
Noise level	<55dB (A)

Technical Standards	Technical Parameters
The channel size	500(W)×300(H)mm
Conveyor speed	0.22m/s
Load	20 kg
Resolution	Φ0.0787 mm
Penetration	≥40 mm steel plate
Monitor	Samsung 19in LCD Monitor
Storage	500G hard drive to save any image in real time, can store more than 100,000 and can make any image processing, and continuous work to save.
Noise	< 55dB(A)
Operating system	windowsXP
Film Safety	Safety to the ISO1600
Leaking radiation dose rate	Away from any device outer surface of 5cm, the ray irradiation leak rate should be < 0.05µGy/H
Dimensions	(L) 1750mm (W)750mm(H)1300mm
NW / GW	290 kg / 360 kg

Applications

Customs, port, prosecutors, prisons, railway stations, courts and other security units.

Packaging & Shipping

Strong plywood box

delivery by air or by sea

Our Services

our engineer can give full life of the machine repair and daily life support

our sales team can give your feedback within 12 hours after receive your inquiry

Company Profile

Dongguan V Finder Electronic Technology Co., Ltd.

DongGuan V Finder Electronic Technology Co;Ltd is a professional Large Scale manufacture of all types of Industrial metal detector,Security metal detector . Security x ray machine .check weigher integrating development and production together . All of our products concentrate and center on detection measurement technology .Our mainly products includes walk through metal detector.hand held metal detector.food metal detector .industrial metal detector .ground metal detector . Security x-ray baggage luggage scanner . Check weigher .weight detector. Needle inspection and detector and related products .Our company Located in the manufacture of capital "DongGuan City .Between Guangzhou and HongKong. We enjoy convenient Express. Air and Sea transportation Our company employee more than 50 workers. Through the efforts of our entire stuff . Our products already widely used in the international market.We have the customers in USA. Australia .Brazil.Educator.Germany.Greece Russia ,Nigeria .Saudi Arabic ,Ukraine.Bulgaria and other 40 countries . On last and this year our security metal detector and x ray baggage scanner successful finished support 2015 Nigeria President election security Mission. Outstanding finished the GuangDong International Modern furniture Fair and the 2015 Sudirman Cup Security protection . Our company promise : reasonable prices, short production time satisfactory after-sales service Mutual development, mutual benefits Our company can supply :Free logo printing Free model design Free solution adviser Full OEM and ODM We have a improve PMC control .Quality assurance and strictly Quality control Section . From material enter into our basis and before shipping . It will go through a overall strict inspection . We welcome new and old customers contact us for future business relationships and mutual success!
