Help CenterSubway Station X-ray Luggage Scanner, Xray Dangerous Baggage Scanner, Xray Baggage Scanner
Related Products
-
Smith X-ray Baggage Scanner / X Ray Luggage, Baggage Scanner in ChinaUS$ 17,500 - 19,000MOQ: 1 Set -
100100 X-ray Luggage Scanner, X-ray Baggage Scanner Inspection SystemUS$ 17,500 - 19,000MOQ: 1 Set
-
Lcd Display X-ray Luggage Scanner Airport X-ray Screening Machine Court x Ray Luggage Checking ScannerUS$ 17,500 - 19,000MOQ: 1 Set
-
Xray Luggage Scanner Hotel Security Baggage Scanner Made in ChinaUS$ 17,500 - 19,000MOQ: 1 Set
-
Large Tunnel Size 34mm Armor Plate Steel Penetration X-ray Luggage Scanner for AirportUS$ 17,500 - 19,000MOQ: 1 Set
VX100100 X Ray Baggage Scanner 1024 * 1280 pixel For Courthouses
Tunnel Size: |
1000(W)*1000(H)mm |
Conveyor Speed: |
0.22m/s |
Conveyor Max Load: |
200kgs |
Dose per Inspection: |
<1.7μGy/h |
Resolution: |
<0.101mm Metal Wire |
Penetration: |
34mm Steel |
Film Safety: |
Guarantee ISO1600 Film |
X-ray Leakage: |
<0.1μGy/h (at a distance of 5cm From external housing) |
Generate direct: |
downward |
Generate angle: |
80 degree |
Anode Voltage: |
100-160Kv |
Anode power: |
0.4 to 1.2mA |
Cooling / Duty Cycle: |
Oil Cooling /100% |
X-ray Sensor: |
L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
Monitor: |
High Resolution Color, LCD Accord, 17 inch |
Image Processing: |
Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
Image Grey Level: |
4096 |
Image Max Resolution: |
1024 * 1280 pixel |
Image Processing: |
24bit for processing real time |
Image storage: |
Storage 60000 pictures in real time |
Zones & Zoom: |
1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
Operation temperature/Humidity: |
0℃-45℃/20%-95%(non-condensing) |
Storage Temperature/Humidity: |
-20℃-60℃/20%-95%(non-condensing) |
Operation Power: |
220VAC(±10%)50±3Hz |
Power Consumption: |
1.8 KW (max), 0.3KW(working) |
Noise: |
<58db |
Applications:
01. Airports,
02. Transport terminals,
03. Buildings,
04. Factories (to find needle in clothing, shoes, bags),
05. Courthouses,
06. Embassies,
07. Military installations,
08. Prisons,
09. Hotels,
10. Schools ,
11. Convention centers,
12. Security checkpoints
13. Special events location
Competitive Advantage:
1. Integrated, cost Effective, Turn-Key Security
2. Fit for small Baggage and Parcel Security Inspection.
3. Increased detection capability
4. Friendly interface for ease-of-use
5. Reliable performance and uncompromising value
strong plywooden case support delivery by sea or by air
EXW FOB CIF term is acceptable
engineer can go overseas for big project design and guidance
