Dong Guan V finder electronic technology co;ltd is a professional needle detector .
metal detector and related industry equipment manufacture .
We produce and customized various kinds of hand held needle detector.table needle detector . Conveyor belt needle detector . Conveyor belt metal detector and so on related
Equipment .
New Function :
Newly design twin sensor head with different angle
The newly designed twin sensor head are set at different angle to achieve precise detection
Blue back LCD panel
Improved visibility&operatively Optional touch screen
New sensitivity level monitor
Unique new monitor provide more detail detection result
Conveyor reverse function
Conveyor reverse function will be helped for easy operation
Products counter .alarm counter
Counter function is equipped as standard
Printer (Optional)
Optional data printer function. Easy for report
General Specifications
Equipped with Vfinder microcomputer chips from USA for digital signal management, it can analyze the different channel signals and improved the detection reliability.
Special inducing design in the detection field, the sensitivity and anti-disturbance ability are greatly improved, and it is not disturbed by the environment.
Unique inducting design of balanced magnetic field to meet the needs of different clients, especially for the detection of garment accessory.
With digital display in Chinese, touching screen of films. It is convenient for operation and management.
The perfect combination of powerful functions and simple operation is also a friendly philosophy of design.
Equipped with the intellectual location displaying system, which can indicate the location of the needle.
The intellectual counter system can calculate the qualified and unqualified objects amount.
Equipped with safe lock only, which can lock the sensitivity, so that it is convenient for management.
Digital sensitivity regulation, the induction strength can show the disturbance and Iron content.
Equipped with light control automatic alarm and automatic power off function.
Short parameter :
MODEL |
VFG-900 |
||||
Detection method |
Magnetic induction.digital process double sensor |
||||
Detection ability |
≥FeΦ0.8 |
≥FeΦ0.8 |
≥FeΦ1.0 |
≥FeΦ1.2 |
≥FeΦ1.5 |
Detection Height |
100mm |
120mm |
150mm |
200mm |
250mm |
Detection width |
Net width 600mm-non-standard sizes(custom) |
||||
Detection adjustment |
Touch screen adjust the level 1-12 |
||||
Alarm method |
Sound/light alarm and return, then restarts again |
||||
Power supply |
Ac220V 50-60Hz |
||||
Pated output |
140W |
||||
Machine Size |
L1820mm×W1050mm×H900mm |
||||
Weight |
280KG |
||||
Use Range :
Garment .Textile.underwear .towel. Sanitary and so on industry .
we takes of ploywood case that suitable for export
Shipment according to customer can by air by sea or by railway station
our sales will reply you within 12 hours after receive your iquiry
our after sales department can give your full english after sales service
Our enigneer can go overseas to for big project design and guide
we are a professional needle metal detector and conveyor belt full meal detector manufacture located in Guang Dong city of China. we accept different kinds of OEM and ODM serice
