Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Wire > 15.24 mm PC Steel Strand

15.24 mm PC Steel Strand

Name: 15.24 mm PC Steel Strand
Brand: efya
SKU: 143796276
Availability: InStock

US$ 600 - 750 MOQ: 10 Tons

Key Specifications

Get Latest Price

Steel Grade:

SWRH82B, High carton steel wire 82B

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge:

15.24

Contact Supplier Request Quote Chat Now

Efya International Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang Tianjin China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Steel Grade SWRH82B, High carton steel wire 82B

Standard AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge 15.24

Place of Origin Tianjin, China

Type Other, pc strand

Application Construction

Alloy Or Not Non-alloy

Special Use Cold Heading Steel

Model Number AL01-6

Brand Name efya

Specifications

1.PC Strand 7 wires 3 / 5 '' ASTM A416 1860Mpa
2.Actual Tensile Strength above 1860Mpa
3.Material: SWRH82B

15.24 mm PC steel Strand

15.24 mm PC steel Strand

1	Type	PC strand , 7 wires, Left Lay,
2	Diameter	15.24 mm , 3/5 inches
3	Construction	1*7 low relaxation pc strand
4	Standard	ASTM A416
5	Re. mass per 1000m(kg/1000m)	775/1102
6	Material	82B
7	Packing	Standard export packing
8	Tensile strength	1860MPa

Mechanics properties of steel strand - ASTM A 416

Grade	Nominal diameter	Tolerance	Nominal Area of Section	Weight per 1000 meterS	Minimum Breaking load not less than	Minimum load at 1% Extension	Elongation not less than	The Relaxation at 1000h (initial load to 70% of nominal max load ) (r/%) Not more than
	(mm)	(mm)	(m2)	(kg)	(KN)	(KN)	(%)	Low Relaxation	Normal-Relaxation
	(mm)	(mm)	(m2)	(kg)	(KN)	(KN)	(%)	70% initial load	80% initial load
250	6.4	±0.40	23.2	182	40	36	3.5	2.5	3.5
	7.9		37.4	294	64.5	58.1
	9.5		51.6	405	89	80.1
	11.1		69.7	548	120.1	108.1
	12.7		92.9	730	160.1	144.1
	15.2		139.4	1094	240.2	216.2
270	9.5	0.65 -0.15	54.8	432	102.3	92.1	3.5	2.5	3.5
	11.1		74.2	582	137.9	124.1
	12.7		98.7	775	183.7	165.3
	15.2		140	1102	260.7	234.6

Product Description

1.PC Strand 7 wires 3 / 5 '' ASTM A416 1860Mpa

2.Actual Tensile Strength above 1860Mpa

3.Material: SWRH82B

15.24 mm PC steel Strand details
