Specifications
JBT30 Concrete Pump With Mixer1.Dual-cylinder hydraulic pumping system
2.Small size and operating space
3.Stable performance
JBT30 Portable Concrete Pump With Mixer
Description of JBT30 Portable Concrete Pump With Mixer :
Concrete mixer pump is a new kind of engineering equipment of the combination of concrete mixer and concrete pump. It uses dual-cylinder hydraulic pumping system, small size and operating space and large concrete pouring and excellent characteristics of the mature and stable performance. The product is suitable for 2 to 12-storey small building construction, and a variety of cave, roads, railway tunnels, water conservancy and hydropower engineering, geological hazards slope treatment works.
Parameters of JBT30 Portable Concrete Pump With Mixer :
Max theoretical concrete conveying capacity | 30m3/h |
Distribution valve model | S tube valves |
Hopper capacity * filling height | 500L* 1200mm |
Pump motor power | 30kw |
Winding motor power | 4kw |
Hydraulic circuit form | Open circuit |
Rated speed | 1480Rmp |
Oil tank volume | 170L |
Weight | 3500kg |
Concrete pumping pressure | 9Mpa |
Concrete cylinder size * length | 180mm*800mm |
Discharge mouth diameter | 180mm |
Mixing motor power | 3*2kw |
Water pump motor power | 550w |
Max aggregate diameter | Pebble: 40mm |
Gravel: 30mm | |
Voltage | 380v |
Dimension(L*W*H) | 4300*2060*3680(mm) |
