Home > Products > Stainless Steel Link Chain > Full Automatic Welded Stainless Steel DIN763 Link Chain,DIN763 316 Stainless Steel Chain
Full Automatic Welded Stainless Steel DIN763 Link Chain,DIN763 316 Stainless Steel Chain
- QINGDAO
- T/T Credit Card
You May Like
-
SUS304/316 Stainless Steel Welded Standard Link Chain
-
High Quality 304 Stainless Steel Link Chain
-
China OEM with bigger sub link g100 master link assembly
-
China OEM wholesale 10mm short link stainless steel chain
-
China OEM welded lashing chain lifting chain g80 chain with fully automatic welded machine
-
China OEM truck tire protection chain for 16/70-20
Product Details
| Place of Origin | Shandong, China | Brand Name | shuguang | |
| Model Number | DIN763 Link Chain | Structure | Welded Chain | |
| Function | Drag Chain | Material | Other, Q235,Q195,Carbon Steel | |
| Standard or Nonstandard | Standard |
Product Description
Specifications
1.DIN763 Link Chain2.Certificate:ISO9001:2008
3.High Quality
4.Surface:Galvanized
1)We have strong technical force,advanced equipment.
2)We produce regular steel link chains,high tensile chains,stainless chains.
knotted chains and animal chains,covering over 300 sizes and specifications.
3)Our products have been exported to the US,Canada,Europe and more than 20 countries and regions.
4)We are the manufacturer,so competitive price and high quality can supply you.
| M.O.Q | 1Ton |
| Trade Terms | FOB,CIF,CFR |
| Payment | L/C,T/T,Western Union |
| Material | Q235,Q195,Carbon Steel,20Mn2 |
| Packaging | Gunny Bag,Steel Drum,Wooden Case,Pallet |
| Surface | Self Color,Zinc Plated,Black,HDG |
| Delivery Time | Within 30 days after received the 30% in advance by T/T |
Specification:
DIN763 Link Chain:
SIZE | INSIDE LENGHT | OUTSIDE WIDTH | WORKING LOAD | TEST LOAD | BREAKING LOAD | WEIGHT PER M | |||
MM | ±AMM | MM | ±MM | MM | ±AMM | KG | N | N | KG |
2 |
0.5
| 22 | 1.0 | 8 | 0.4 | 25 | 800 | 1250 | 0.06 |
2.5 | 24 | 1.1 | 10 | 0.5 | 40 | 800 | 2000 | 0.10 | |
3 | 26 | 1.2 | 12 | 0.6 | 55 | 1050 | 3200 | 0.15 | |
3.5 | 28 | 1.3 | 14 | 0.7 | 80 | 1540 | 3850 | 0.20 | |
4 | 32 | 1.5 | 16 | 0.8 | 100 | 2500 | 6000 | 0.27 | |
4.5 | 34 | 1.7 | 18 | 0.9 | 128 | 3000 | 6300 | 0.35 | |
5 | 35 | 1.8 | 20 | 1 | 160 | 4000 | 10000 | 0.43 | |
5.5 | 38.5 | 1.8 | 22 | 1.1 | 195 | 4200 | 9500 | 0.52 | |
6 | 42 | 2 | 24 | 1.2 | 224 | 5000 | 14000 | 0.63 | |
7 | 49 | 2.5 | 28 | 1.4 | 300 | 7500 | 18000 | 0.86 | |
8 | 52 | 2.5 | 32 | 1.6 | 400 | 10000 | 25000 | 1.1 | |
8.5 | 56 | 2.8 | 34 | 1.7 | 460 | 10200 | 22500 | 1.25 | |
9 | 59 | 3.0 | 36 | 1.8 | 530 | 10500 | 32000 | 1.41 | |
10 | 1 | 65 | 3.2 | 40 | 2.0 | 630 | 16000 | 40000 | 1.75 |
11 | 72 | 3.4 | 44 | 2.0 | 790 | 15800 | 47500 | 2.11 | |
12 | 78 | 3.6 | 48 | 2.3 | 940 | 18800 | 56500 | 2.55 | |
13 | 82 | 4 | 52 | 2.5 | 1000 | 25000 | 63000 | 2.95 | |
16 | 100 | 5 | 64 | 3.2 | 1600 | 40000 | 100000 | 4.45 | |
18 | 113 | 5.2 | 70 | 3.2 | 2120 | 42300 | 127000 | 5.65 | |
19 | 119 | 5.6 | 72 | 3.4 | 2370 | 47300 | 142000 | 6.25 | |
20 | 120 | 6 | 75 | 3.8 | 2500 | 50000 | 160000 | 7.0 | |
22 | 127 | 6 | 82 | 4.0 | 3170 | 63300 | 190000 | 8.55 | |
1)Weldless chain
2)Animal chain
3)Stainless steel link chain
4)G30 proof coil chain
5)Ordinary mild steel link chain
6)Norwegian standard link chain
7)Korean standard link chain
8)NACM1990 standard link chain
9)ASTM80 standard link chain
10)NACM96 standard link chain
11)Australian standard link chain
12)DIN5685,DIN764,DIN763,DIN766
Products Pictures:
4.Factory and Equipment:
Reel+Pallet/Wooden
Steel Drum+Pallet
Wooden Case+Pallet
Gunny Bag+Pallet
Plastic Drum+Pallet
Carton+Pallet
And we can pack according to your requirements
6.Please contact me:
Contact Us
- Linyi Hedong Shuguang Rigging Factory
- Contact nameMelody Liu Chat Now
- Phone86-0539-15725199659
- AddressQingdun Temple Village, Xiang Gong Office, Hedong Dist., Linyi, Shandong
