Hot Dip Galvanized DIN766 Short Link Chain On Hot Selling
US$ 1,230 - 3,000
MOQ: 1 Ton
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Shuguang
Model Number:
DIN766 Link Chain
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GALV. SHORT LINK CHAIN DIN766 LINK CHAINUS$ 660 - 1,500MOQ: 3 Tons -
Factory Supply Electro Galvanized Welded DIN766 Link ChainUS$ 1,200 - 3,000MOQ: 1 Ton
-
Galvanized G30 Chain Ordinary Mild Steel Link Chain With Good QualityUS$ 650 - 750MOQ: 3 Tons
-
Germany Standard Link ChainsUS$ 400 - 2,500MOQ: 5 Tons
-
Grade 30 1/4" Diameter Grade 30 Proof Coil ChainUS$ 650 - 750MOQ: 10 Tons
Place of Origin
Shandong, China
Brand Name
Shuguang
Model Number
DIN766 Link Chain
Structure
Welded Chain
Function
Drag Chain
Material
Other, Q235,Q195,Carbon Steel
Standard or Nonstandard
Standard
Specifications
1.DIN766 Link Chain2.Certificate:ISO9001:2008
3.High Quality
4.Surface:Galvanized
1.Company Information:
1)We have strong technical force,advanced equipment.
2)We produce regular steel link chains,high tensile chains,stainless chains.
knotted chains and animal chains,covering over 300 sizes and specifications.
3)Our products have been exported to the US,Canada,Europe and more than 20 countries and regions.
2.Product Description:
| M.O.Q | 1Ton |
| Trade Terms | FOB,CIF,CFR |
| Payment | L/C,T/T,Western Union |
| Material | Q235,Q195,Carbon Steel,20Mn2 |
| Packaging | Gunny Bag,Steel Drum,Wooden Case,Pallet |
| Surface | Self Color,Zinc Plated,Black,HDG |
| Delivery Time | Within 30 days after received the 30% in advance by T/T |
Specification:
Germany DIN766 Link Chain:
| Size | Inside Length | Inside Width | Outside Width | Length Per 11 Links | Weight Per M | |||||
| MM | ±MM | MM | +MM | -MM | MM | MM | MM | +MM | -MM | KG |
| 2 | 0.2 | 12 | 0.2 | 0.2 | 3.5 | 7.5 | 132 | 1.0 | 0.5 | 0.07 |
| 3 | 0.2 | 16 | 0.2 | 0.2 | 4.2 | 11 | 176 | 1.4 | 0.7 | 0.16 |
| 4 | 0.2 | 16 | 0.3 | 0.2 | 5 | 13.7 | 176 | 2.1 | 1.1 | 0.32 |
| 5 | 0.2 | 18.5 | 0.4 | 0.2 | 6 | 17 | 203.5 | 2.4 | 1.2 | 0.5 |
| 6 | 0.2 | 18.5 | 0.4 | 0.2 | 7.2 | 20.2 | 203.5 | 2.4 | 1.2 | 0.8 |
| 7 | 0.3 | 22 | 0.4 | 0.2 | 8.4 | 23.8 | 242 | 3.0 | 1.4 | 1.1 |
| 8 | 0.3 | 24 | 0.4 | 0.2 | 9.6 | 27.2 | 264 | 3.2 | 1.5 | 1.4 |
| 9 | 0.4 | 27 | 0.5 | 0.3 | 10.8 | 30.6 | 297 | 3.6 | 1.8 | 1.8 |
| 10 | 0.4 | 28 | 0.5 | 0.3 | 12 | 34 | 308 | 3.7 | 1.9 | 2.2 |
| 11 | 0.4 | 31 | 0.5 | 0.3 | 13.2 | 37.4 | 341 | 4.0 | 2.0 | 2.7 |
| 12 | 0.3 | 36 | 0.6 | 0.3 | 14.4 | 40.8 | 396 | 4.4 | 2.2 | 3.10 |
| 13 | 0.5 | 36 | 0.6 | 0.3 | 15.6 | 44.2 | 396 | 4.6 | 2.4 | 3.8 |
| 14 | 0.6 | 41 | 0.7 | 0.4 | 16.8 | 47.6 | 451 | 5.4 | 2.7 | 4.4 |
| 16 | 0.6 | 45 | 0.8 | 0.4 | 19.2 | 54.4 | 495 | 6.0 | 3.0 | 5.7 |
| 18 | 0.9 | 50 | 0.8 | 0.4 | 21.6 | 61.2 | 550 | 6.6 | 3.3 | 7.3 |
| 19 | 0.4 | 53 | 0.9 | 0.4 | 22.8 | 64.6 | 583 | 7.0 | 3.7 | 7.97 |
| 20 | 1.0 | 56 | 1.0 | 0.5 | 24.0 | 68.0 | 616 | 7.4 | 3.7 | 9.0 |
| 22 | 1.2 | 62 | 1.1 | 0.5 | 26.4 | 75.0 | 682 | 8.0 | 4.0 | 11.0 |
| 23 | 1.2 | 64 | 1.1 | 0.5 | 27.6 | 78.2 | 704 | 8.4 | 4.2 | 12 |
| 26 | 1.3 | 73 | 1.2 | 0.6 | 31.2 | 88.4 | 803 | 9.6 | 4.8 | 15 |
3.Our Services:
We can offer the following products:
1)Weldless chain
2)Animal chain
3)Stainless steel link chain
4)G30 proof coil chain
5)Ordinary mild steel link chain
6)Norwegian standard link chain
7)Korean standard link chain
8)NACM1990 standard link chain
9)ASTM80 standard link chain
10)NACM96 standard link chain
11)Australian standard link chain
12)DIN5685,DIN764,DIN763,DIN766
Products Pictures:
4.Factory and Equipment:
5.Packaging & Shipping:
And we can pack according to your requirements
