Pole Mount Radar Speed Signs / Portable Traffic Flashing Speed Limit Signs LED Warning Sign Powered Solar Radar Speed Sign

Details

By far the most common application of Ambund radar speed signs is for traffic calming in locations where motorists regularly travel at unsafe speeds over the posted speed limit, including school zones, neighborhoods, and high-incident locations.

Ambund radar-speed signs feature configurable settings and input for auxiliary equipment, such as caution beacons. Above the user-configured speed setting, the sign flashes the motorist’s speed. At excessive speeds, the sign flashes a user-selected message. Below the speed limit, the display remains blank.

The speed display includes optical lenses and sun shades over bright LED characters, producing superior visibility. The display is available with 13 or 26 inch characters. Both sizes can display two characters for miles per hour and three characters for kilometers per hour.

A typical pole-mount configuration includes the speed display, a control box, battery box, solar panel, and all necessary wiring. A regulatory speed limit sign is optional, as are a variety of auxiliary devices.

Features

Configurable speed settings and operating modes
Optical lenses and sun shades over high-output LED characters ensure outstanding visibility and legibility
Choose either 13-inch or 26-inch character size to suit the application

Display flashes vehicle’s speed if above the set speed limit
Display flashes user-selected “excessive speed” message if a vehicle exceeds 130% of the set speed limit
Approach-only K-band radar measures speeds from 5 to 138 mph (8 to 222 km/h), at a distance of up to 1000 feet (305 meters)

Software-controlled selection of speed units, mph or km/h
Radar unit is CE compliant, FCC approved
Signs feature standard mounting for a 4½-inch OD round pole
Commercial AC powered, or battery powered with solar-based charging system

Regulator shuts down solar charging system when batteries are fully charged, preventing damage
Weather-resistant steel box houses electronics and control panel, which includes LED status indicators
Standard aluminum enclosure houses batteries, and features a police-lock for security

Options†

Display
13- or 26-inch characters
MPH or km/h units
Red-and-blue flashers
White flashers
Strobe

System
Caution beacons
Choice of R2-1 regulatory signs
Choice of mounting brackets
Aluminum pole, 4-inch diameter (4½-inch OD), 14 feet tall, with pedestal base

Accessories
Programmable 365-day timer for unattended operation
Radar-based traffic counter

 Dimensions — inches (cm)

 SMALL SIGN

LARGE SIGN

Construction

Power
