Specifications
Heavy Duty Layflat HoseThis heavy duty water discharge long time service in applications such as agriculture, constructionHeavy Duty Layflat Hose
This hose is designed for heavy duty water discharge service in applications such as agriculture, construction, industry , marine industry, oil and mining. Abrasion resistant PVC cover,the PVC tube and high adhesions between the layers provide for a long service life. Rolls up flat for easy storage.
- Length: 20m,30m,50m,100m. (50ft,100ft,150ft,300ft)
- Size: 38mm,50mm,63mm,76mm,100mm,150mm,200mm
- Working pressure: 6bar/90psi, 8bar/120psi , 10bar/150psi
- Cover(outside&inside): Yellow ,Red,Black,Orange,Blue PVC - rough surface
- Reinforcement: Hi-strength terylene yarn
- Brand: TianQuan
- Temperature range: -60° C to +50°C
Key Features:
- Heavy duty hose
- Very high abrasion resistance
- Resistant to oil, fuel and chemical products
- Lightweight, flexible and kink resistant
- Low maintenance and easy to clean
- Requires no drying after use
British | Metric Measurement | Working | Bursting | Weight | ||
measurement | I.D. | O.D. | Length | Pressure | Pressure | |
inch | mm | m | Mpa | Mpa | kg/roll | |
2 | 51 | 55.4 | 30 | 1.0 | 2.0 | 12.96 |
51 | 56 | 30 | 1.5 | 3.0 | 14.73 | |
51 | 56.6 | 30 | 2.0 | 4.0 | 16.5 | |
51 | 57.4 | 30 | 2.5 | 5.0 | 43.5 | |
2.5 | 65 | 69.4 | 30 | 1.0 | 2.0 | 16.5 |
65 | 70 | 30 | 1.5 | 3.0 | 18.78 | |
65 | 70.6 | 30 | 2.0 | 4.0 | 21 | |
65 | 71.4 | 30 | 2.5 | 5.0 | 55.5 | |
3 | 76 | 80.4 | 30 | 1.0 | 2.0 | 19.32 |
76 | 81.2 | 30 | 1.5 | 3.0 | 22.83 | |
76 | 82 | 30 | 2.0 | 4.0 | 26.34 | |
4 | 102 | 106.8 | 30 | 1.0 | 2.0 | 28.26 |
102 | 107.6 | 30 | 1.5 | 3.0 | 33 | |
102 | 108.4 | 30 | 2.0 | 4.0 | 37.8 | |
6 | 150 | 154.4 | 30 | 0.8 | 1.6 | 39 |
150 | 155.6 | 30 | 1.0 | 2.0 | 49.5 | |
150 | 156.4 | 30 | 1.3 | 2.6 | 56.55 | |
8 | 200 | 205 | 30 | 0.8 | 1.6 | 58.8 |
200 | 206.4 | 30 | 1.0 | 2.0 | 75.3 | |
Hi-strength terylene yarn and qualified PVC synthesis materials.Light weight
good flexibility, bright color, smooth smearing layer. Flat roll and easy for take
back,convenient for moving and non limitation for length Capable for keeping
the flexibility and elasticity under the low-temperature water.Anti-hi pressure
corrosion resistance and ageing resistance.Applied to the lines of theauxilia-
ries for agricultural tools against the drought, project, miming, environment
protection, industry and so on, which is the most ideal liquid-transferred hi-
pressure hose.Applicable operation temperature 10Degree-60Degree
Material: halogenated paraffin,dibutyl ester,polyethylene,calcium carbonate.
Send Inquiry to This Supplier
