Australia Standards PVC Telecom Conduit Bend, Telecom PVC Conduit Bend, Communication Bends, Telecom Bends AS/NZ 2053

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port SHANGHAI
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China	Brand Name	TOTAL
Model Number	AS2053	Material	PVC
Standard	AS2053-2:2001

Product Description

PVC electrical conduit, PVC electrical conduit fittings, electrical PVC conduit, PVC communications conduit, PVC conduit, PVC pipe, PVC conduit, conduit pipe, pipe fittings

Name	ITEM CODE	SIZE	O.D. (mm)	W.T.(mm)		Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
Name	ITEM CODE	SIZE	O.D. (mm)	Min	Max	Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
Rigid MD Electrical Conduitwith Belled Ends AS2053-2:2001 (standard color Grey, can be also Orange)	ACMD16	16	15.7-16.0	1.6	1.9	400	2.0	0.49	Medium
	ACMD20	20	19.7-20.0	1.8	2.1	400	3.5	0.68	Medium
	ACMD25	25	24.7-25.0	1.8	2.1	400	4.0	0.87	Medium
	ACMD32	32	31.7-32.0	2.1	2.4	400	5.0	1.31	Medium
	ACMD40	40	39.7-40.0	2.4	2.7	400	6.0	1.87	Medium
	ACMD50	50	49.7-50.0	2.8	3.1	400	6.5	2.72	Medium
	ACMD63	63	62.7-63.0	3	3.5	400	7.5	3.84	Medium
	ACMD80	80	88.7-89.1	3.5	4.1	400	9.5	6.45	Medium
	ACMD100	100	114.1-114.5	4.5	5.2	400	12.0	10.58	Medium
	ACMD150	150	160.0-160.5	6.3	7.1	400	16.5	20.63	Medium
	ACMD16	16	15.7-16.0	1.6	1.9	560	2.0	0.68	Medium
	ACMD20	20	19.7-20.0	1.8	2.1	560	3.5	0.95	Medium
	ACMD25	25	24.7-25.0	1.8	2.1	560	4.0	1.21	Medium
	ACMD32	32	31.7-32.0	2.1	2.4	560	5.0	1.81	Medium
	ACMD40	40	39.7-40.0	2.4	2.7	560	6.0	2.6	Medium
	ACMD50	50	49.7-50.0	2.8	3.1	560	6.5	3.78	Medium
	ACMD63	63	62.7-63.0	3	3.5	560	7.5	5.35	Medium
	ACMD80	80	88.7-89.1	3.5	4.1	560	9.5	8.95	Medium
	ACMD100	100	114.1-114.5	4.5	5.2	560	12.0	14.64	Medium
	ACMD150	150	160.0-160.5	6.3	7.1	560	16.5	28.6	Medium
Rigid HD Electrical Conduit with Belled Ends AS2053-2:2001 (standard color Orange)	ACHD20	20	19.7-20.0	2.3	2.6	400	3.5	0.83	Heavy
	ACHD25	25	24.7-25.0	2.5	2.8	400	4.0	1.15	Heavy
	ACHD32	32	31.7-32.0	2.7	3	400	5.0	1.62	Heavy
	ACHD40	40	39.7-40.0	3.1	3.4	400	6.0	2.34	Heavy
	ACHD50	50	49.7-50.0	3.4	3.9	400	6.5	3.32	Heavy
	ACHD63	63	62.7-63.0	3.9	4.5	400	7.5	4.89	Heavy
	ACHD80	80	88.7-89.1	4.6	5.3	400	9.5	8.3	Heavy
	ACHD100	100	114.1-114.5	5.9	6.7	400	12.0	13.5	Heavy
	ACHD150	150	160.0-160.5	8.3	9.3	400	16.5	26.72	Heavy
	ACHD40	40	39.7-40.0	3.1	3.4	560	6.0	2.34	Heavy
	ACHD50	50	49.7-50.0	3.4	3.9	560	6.5	4.62	Heavy
	ACHD63	63	62.7-63.0	3.9	4.5	560	7.5	6.81	Heavy
	ACHD80	80	88.7-89.1	4.6	5.3	560	9.5	11.44	Heavy
	ACHD100	100	114.1-114.5	5.9	6.7	560	12.0	18.77	Heavy
	ACHD150	150	160.0-160.5	8.3	9.3	560	16.5	37.05	Heavy
Name	ITEM CODE	SIZE	O.D. (mm)	W.T.(mm)		Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
Name	ITEM CODE	SIZE	O.D. (mm)	Min	Max	Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
Rigid MD(UV Resistant) Electrical Conduit with Belled Ends AS2053-2:2001 (standard color White, can be also Grey)	AS01016	16	15.7-16.0	1.6	1.9	400	2.0	0.49	Medium
	AS01020	20	19.7-20.0	1.8	2.1	400	3.5	0.68	Medium
	AS01025	25	24.7-25.0	1.8	2.1	400	4.0	0.87	Medium
	AS01032	32	31.7-32.0	2.1	2.4	400	5.0	1.31	Medium
	AS01040	40	39.7-40.0	2.4	2.7	400	6.0	1.87	Medium
	AS01050	50	49.7-50.0	2.8	3.1	400	6.5	2.72	Medium
	AS01063	63	62.7-63.0	3	3.5	400	7.5	3.84	Medium
	AS01080	80	88.7-89.1	3.5	4.1	400	9.5	6.45	Medium
	AS01100	100	114.1-114.5	4.5	5.2	400	12.0	10.58	Medium
	AS01150	150	160.0-160.5	6.3	7.1	400	16.5	20.63	Medium
	AS01080	80	88.7-89.1	3.5	4.1	560	9.5	8.95	Medium
	AS01100	100	114.1-114.5	4.5	5.2	560	12.0	14.64	Medium
	AS01150	150	160.0-160.5	6.3	7.1	560	16.5	28.6	Medium
Rigid LD Electrical Conduit with Belled Ends AS2053-2:2001	AS01040	40	39.7-40.0	2	2.6	400	6.0	1.7	Light
	AS01050	50	49.7-50.0	2.2	2.6	400	6.5	2.25	Light
	AS01100	100	114.1-114.5	2.9	3.4	400	12.0	6.98	Light

Name	ITEM CODE	SIZE	O.D. (mm)	W.T.(mm)		Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
Name	ITEM CODE	SIZE	O.D. (mm)	Min	Max	Length (cm)	Socket Length (cm)	Weight (kgs)	Gauge
telecom bend (green or white)	ASTB20-90-100	26.8mm (3/4")/90°	26.8 (+/-0.25)	1.8 (+/-0.1)			38mm
telecom conduit (green or white)	ASTC26.8	26.8mm (3/4")	26.8 (+/-0.25)	1.8 (+/-0.1)		600

Descirption	Size mm	Item No.	Load Capacity	outside diameter(MM)	Wall thickness(MM)	Length(M)
(UK standards / Europe standards) Rigid PVC Conduit	16	CC01016	Light	15.7 - 16.0	1.0-1.1	4
	20	CC01020	Light	19.7 - 20.0	1.1-1.2	4
	25	CC01025	Light	24.6 - 25.0	1.3-1.4	4
	32	CC01032	Light	31.6 - 32.0	1.45-1.5	4
	40	CC01040	Light	39.6 - 40.0	1.45-1.5	4
	50	CC01050	Light	49.5 - 50	1.9-2.0	4
	16	CC02016	Medium	15.7 - 16.0	1.20-1.35	4
	20	CC02020	Medium	19.7 - 20.0	1.35-1.45	4
	25	CC02025	Medium	24.6 - 25.0	1.55-1.65	4
	32	CC02032	Medium	31.6 - 32.0	1.8-1.9	4
	40	CC02040	Medium	39.6 - 40.0	1.9-2.0	4
	50	CC02050	Medium	49.5 - 50	2.5-2.6	4
	16	CC03016	Heavey	15.7 - 16.0	1.7-1.9	4
	20	CC03020	Heavey	19.7 - 20.0	2.0-2.2	4
	25	CC03025	Heavey	24.6 - 25.0	2.1-2.3	4
	32	CC03032	Heavey	31.6 - 32.0	2.2-2.4	4
	40	CC03040	Heavey	39.6 - 40.0	2.5-2.7	4
	50	CC03050	Heavey	49.5 - 50.0	2.8-3.0	4
	63	CC03063	Heavey	62.4 63.0	3.1-3.3	4

Other length is available.
