Home > Products > New Products > Toyota 4Y engine(2Y/3Y/4Y/4YEFI/2L/3L/5L/2RZ/22R)
Toyota 4Y engine(2Y/3Y/4Y/4YEFI/2L/3L/5L/2RZ/22R)
- 1000 Unit / Units per Month
- shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Heilongjiang, China | Brand Name | Toyota | |
| Model Number | 4Y | Warranty | 1 year |
Product Description
Specifications
Toyota 4Y engine1. OEM quality and good service
2. Competitive price and fast shipment
3. Professional company
Specifications and Description:
Line | Item | Specifications and Description |
1 | Model | Toyota 4Y |
2 | Type | 4 stroke, water cooling, inline, wedge shape combustion chamber |
3 | Cylinders | 4 |
4 | Bore | 91 mm |
5 | Stroke | 86 mm |
6 | Displacement | 2.237 L |
7 | Power / RPM | 68 kw / 4,200-4,600 rpm |
8 | Idle speed | 750 ± 50 rpm |
9 | Max. torque/RPM | 177N.m / 2,800-3,200 rpm |
10 | Fuel supply | Carburetor |
11 | Fuel | RON 90 (GB484) |
12 | Min. fuel consumption | ≤ 285 g / kw.h |
13 | Oil | SE 10 W-30 or SE 15 W-40 (GB11121) |
14 | Oil consumption | ≤ 0.8 % |
15 | Piston average speed | 13.19 m / s |
16 | Crankshaft rotation (facing to flywheel) | anticlockwise |
17 | Compression ratio | 8.8 |
18 | Weight vs. power | 2.25 kg / kw |
19 | Average efficient pressure | 793 kPa |
20 | Power vs. displacement | 30.4 kw / l |
21 | Ignition order | 1-3-4 -2 |
22 | Distributing | |
Intake in advance | 12 ° | |
Intake in lag | 48 ° | |
Exhaust in advance | 54 ° | |
Exhaust in lag | 10 ° | |
23 | Cooling | Centrifugal water pumped cycling |
24 | Lubricating | Pressed and splashed |
25 | Starting | Electric starter |
