Specifications
cummins marine engine 6BT5.9-M120Cylinders 6
Displacement 8.3L
Bore 114mm
Stroke 135mm Fuel System PB/R801
cummins marine engine 6CTA8.3 M205
Displacement 8.3L
Bore 114mm
Cylinders 6
Stroke 135mm
Fuel System PB/R801
Technical Specification
Aspiration Turbocharged & After-cooled
Turning count-clockwise (face to flywheel)
Performance Data
Advertised Power/Speed 151kW/2328rpm
Max Power/Speed 166kW/2400rpm
Max Torque 828N.m/1500rpm
Fuel Consumption 247g/kW.h
DCEC-Cummins marine main engine
Model Rated Power (kw/rpm) Max Power (kw/rpm) Intake Way
6BTA5.9-M150 110/2200 120/2200 Turbocharged and intercooled
6CTA8.3-M188 138/2328 152/2328 Turbocharged and intercooled
6CTA8.3-M205 151/2328 166/2328 Turbocharged and intercooled
6CTA8.3-M220 164/1800 180/1800 Turbocharged and intercooled
6CTAA8.3-M260 190/2134 209/2134 Turbocharged and air to air intercooled
6LTAA8.9-M300 224/1800 245/1800 Turbocharged and air to air intercooled
6LTAA8.9-M315 230/2134 253/2134 Turbocharged and air to air intercooled
Note:All the aboce engine model have got the type approval certification of CCS.Some have procured IMO emission certification.
| DCEC-Cummins marine main engine | |||
| Model | Rated Power (kw/rpm) | Max Power (kw/rpm) | Intake Way |
| 6BTA5.9-M150 | 110/2200 | 120/2200 | Turbocharged and intercooled |
| 6CTA8.3-M188 | 138/2328 | 152/2328 | Turbocharged and intercooled |
| 6CTA8.3-M205 | 151/2328 | 166/2328 | Turbocharged and intercooled |
| 6CTA8.3-M220 | 164/1800 | 180/1800 | Turbocharged and intercooled |
| 6CTAA8.3-M260 | 190/2134 | 209/2134 | Turbocharged and air to air intercooled |
| 6LTAA8.9-M300 | 224/1800 | 245/1800 | Turbocharged and air to air intercooled |
| 6LTAA8.9-M315 | 230/2134 | 253/2134 | Turbocharged and air to air intercooled |
| Note:All the aboce engine model have got the type approval certification of CCS.Some have procured IMO emission certification. | |||
