Multi-Application Gold Multifunction 7Kva Diesel Generator

FOB Price

US$ 150 - 25,000 / Set

50 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	JLT,Lion King,Century Power,OEM
Model Number	525043	Output Type	AC Single Phase
Speed	1500-3600	Frequency	50/60HZ
Rated Power	2kw-200kw	Rated Voltage	110,120,220,240208/120v,380/220v,440/254v,480/277v
Rated Current	Depend on the power

Multi-Application Gold Multifunction 7Kva Diesel Generator

Product Description

Features

1. Reliable quality for long life and running stably

2. Efficient air cleaner system

3. Direct injection combustion system

4. Oil alert design avoids engine damage in the low oil level condition

Warranty

3 times testing before shipping

1 year warranty

Container order with 5% free spare part

specification		Diesel Powered
GENERATOR	Type	Disel ganerator
	Voltage Regulate	AVR
	AC Frequency(Hz)	50	60	50	60	50	60
	AC Output Voltage(V)	220/230/240	110/220	380/220	380/220	380/220	380/220
	Cont.AC Output(KW)	5.5	6.0	5.0	5.5	5.5	6.0
	Max.AC Output(KW)	6	6.5	5.5	6.0	6.0	6.5
	DC Output(V/A)	12/8.3		12/8.3		12/8.3
ENGINE	Model	JD188FA		JD186FA		JD188FA
	Type	4-stroke,single cylinder with air-cooled
	Bore X Stroke(mm)	88 X 72		86 X 72		88 X 72
	Displacement(ml)	456		418		456
	Max.Output(HP/rpm)	12/3600		10/3600		12/3600
	Fuel	Diesel		Diesel		Diesel
	Fuel Tank Capacity(L)	15		15		15
	Fuel consumption (g/kw.h)	≤282		≤282		≤282
	Lubrication Oil	SAE10W/30		SAE10W/30		SAE10W/30
	Lubrication Oil Capacity (L)	1.65		1.65		1.65
	Starting System	Recoil and Electric
	Operating Noise Level(7m)dB(A)	96		96		96
UNIT	Dimensions L x W x H	710 X 490 X 620		710 X 490 X 620		710 X 490 X 620
	Net Weight (kg)	96		96		96
	Gross Weight (kg)	100		100		100
	20/40FT pcs	99/288		99/288
