Home > Industrial Equipment & Components > Engine & Part > Engine > Standard Chinese Motorcycle Gasoline Motore

Standard Chinese Motorcycle Gasoline Motore

Standard Chinese Motorcycle Gasoline Motore photo-1
Standard Chinese Motorcycle Gasoline Motore photo-2
Standard Chinese Motorcycle Gasoline Motore photo-3
US$ 49 - 349 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Usage:
Boat
Fuel:
Gasoline
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Boat
Fuel Gasoline
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Electric Start
Place of Origin Fujian, China
Brand Name JLT,LION KING
Model Number JP154,JP168,JP168-2.JP170.JP188.JP190
Dimension(L*W*H) 415*360*390
Weight 16KG
Certification CE,ISO,SONCAP
Warranty One year warranty, One year

Specifications

Standard chinese motorcycle gasoline motore
Horizontal shaft
Oil alert
Easy handling
One year warranty

Standard  chinese motorcycle gasoline  motore



gasoline engine, petrol engine, single phase gasoline engine, air cooled gasoline engine, portable gasoline engine,  electric start gasoline engine,  OHV petrol engine, 4-stroke petrol engine.





  • 3HP--15HP gasoline engine
  • One year warranty
  • Container order with 8% free extra spare part



1)Horizontal shaft
2)Oil alert
3)Easy handling

4)Strong power and reliable quality with low noise

5)Cast iron cylinder, more wear-resistant.





FAQ:



1. Q:What is your MOQ  of this item?

 A: Sample order is acceptable.



2. Q: What is the lead time?

A: As usually, 25-35 days after receiving TT deposit or L/C. But we will finish order with shorter time for your urgent need.



3. Q: Where is your loading sea port?

A: Fuzhou, China.



4. Q: Is it all right to make customers own brand name?

A: We can be your OEM manafacture with your authorization of brand..



5. Q: What is your company available production capactiy?

A: One 40HQ container can be finished per day. The more quantities, the same delivery time.





Warranty:



(1) Guarantee for one year or 1000hours (according to whichever reaches first) from ex-factory date.



(2) During guarantee period,our company will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material.







Specifications:


Model GE168FB
GX200
Engine TypeAir-cooled, 4-Stroke, OHV, single cylinder, Gasoline Engine
Bore x Stroke [mm]68*45
Displacement Capacity [cc]196
Compression Ratio8.5 : 1
Net Horse Power Output [hp]6.5
PTO Shaft RotationCounterclockwise (from PTO shaft side)
Ignition SystemTransistorized magneto ignition
Starting SystemRecoil or Recoil/12V Electric
CarburetorHorizontal type butterfly valve
Lubrication SystemForced splash
Governor SystemCentrifugal mechanical
Air CleanerDual element type (opt Cyclone type)
Oil Capacity [Liter]0.6
Fuel Tank Capacity [liter]3.1
Balancing SystemSingle, Counter-Rotating, Balancer Shaft
Length [mm]321
Width [mm]376
Height [mm]335
Dry Weight (Recoil start) [kg]16







Standard chinese motorcycle gasoline motoreStandard chinese motorcycle gasoline motoreStandard chinese motorcycle gasoline motore



We have own factory, then supply lower price and best quality product.

If you have need more information about this series. Please don't hesitable to contact with us.
