Chinese Iron Dredger

Name: Chinese Iron Dredger
Brand: YongSheng
SKU: 143489946
Availability: InStock

US$ 1,000,000 - 1,500,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Cutter Suction Dredger

Power Type:

Diesel

Qingzhou Yongsheng Dredging Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QING DAO Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Cutter Suction Dredger

Power Type Diesel

Dredging Depth 9 m

Place of Origin Shandong, China

Brand Name YongSheng

Model Number CSD200

Weight 60T

Certification ZC

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Qing Zhou Yong Sheng Dredging Machinery CO.,LTD

Specification

SPECIFICAITON OF YS-CSD-200 (dredging depth 9m)
Items	Specs	Remarks
Total Length	21m
Hull Length	14.0m
Hull depth	1.6m
Hull width	4.6m
Main Power	300KW	JICHAI
Auxiliary Engine	24KW HYDRAULIC SYSTEM	WEICHAI POEER
Pump model	WN-200	SHIJIZHUANG
Pump Suction Dia	250mm
Pump Discharge Dia	200mm
Dredging Depth	9m
Water flow	800m^3/h
Discharge Distance	1000m
Working weight	60T
Spuds	325mm Two sets	18m
Winches	3 Sets
Operation System	The most advanced Hydraulic and PLC control system
Spare parts	Tools for disel,oil seal,welders ect 70 items.
Delivery Time	30days

SPECIFICAITON OF YS-CSD-450 (dredging depth 16m)
Items	Specs	Remarks
Total Length	44m
Hull Length	35.0m
Hull depth	2.2m
Hull width	8.0m
Main Power	1200KW	JICHAI
Auxiliary Engine	380KW HYDRAULIC SYSTEM	WEICHAI POEER
Pump model	WN-450	SHIJIZHUANG
Pump Suction Dia	550mm
Pump Discharge Dia	450mm
Dredging Depth	16m
Water flow	1500m^3/h
Discharge Distance	1500m
Working weight	300T
Spuds	630mm Two sets	18m
Winches	3 Sets
Operation System	The most advanced Hydraulic and PLC control system
Spare parts	Tools for disel,oil seal,welders ect 70 items.
Delivery Time	150days
