Help CenterDigging Salt Equipment 10inch
Related Products
Specifications
1.capacity50-4000m3/h,dredging depth4-23m2. function include dredging,crushing,transport salt
Cutter head salt mining dredger / chain bucket dredging salt ship
1.Cutter head salt mining dredger
Dredging salt ship of Yong Sheng shipyard is specially designed for all salterns,which function include dredging,crushing,transport salt .We have manufactured 20 Dredging salt machineries for Shou Guang Salt Field,Mongolia Saltern,Qing Hai Salt Lake and ect.Dredging salt ship can break and crush salt bed,then discharge salt 200-1500m.Dredging salt dredger is operated easily ,antiseptic treatment and durability 20years.Welcome for your coming,we can supply saltern for you to investigate dredging salt machinery efficiency.
.
Cutter suction digging salt ship,salt capacity50-4000m3/h,dredging depth4-23m
2.YS-WYC80 small chain bucket dredging salt ship
Specification of cutter suction digging salt ship,8inch
Items |
Specs |
Remarks |
Total Length |
21m |
|
Hull Length |
14.0m |
|
Hull depth |
1.6m |
|
Hull width |
4.6m |
|
Main Power |
300KW |
|
Auxiliary Engine |
24KW |
WEICHAI POEER |
Pump model |
WN-200 |
SHIJIZHUANG |
Pump Suction Dia |
250mm |
|
Pump Discharge Dia |
200mm |
|
Dredging Depth |
9m |
|
Water flow |
900m^3/h |
|
Discharge Distance |
1000m |
|
Working weight |
60T |
|
Spuds |
325mm Two sets |
18m |
Winches |
3 Sets |
|
Operation System |
The most advanced Hydraulic and PLC control system |
|
Delivery Time |
60days |
|
3.Specification of cutter suction digging salt ship,10inch
Items |
Specs |
Remarks |
Total Length |
25m |
|
Hull Length |
18.0m |
|
Hull depth |
1.6m |
|
Hull width |
5.2m |
|
Main Power |
450KW |
|
Auxiliary Engine |
24KW |
WEICHAI POWER |
Pump model |
WN-250 |
SHIJIZHUANG |
Pump Suction Dia |
300mm |
|
Pump Discharge Dia |
250mm |
|
Dredging Depth |
10m |
|
Water flow |
1200m^3/h |
|
Discharge Distance |
1500m |
|
Working weight |
100T |
|
Spuds |
377mm Two sets |
18m |
Winches |
3 Sets |
|
Operation System |
The most advanced Hydraulic and PLC control system/Electrical System |
|
Delivery Time |
90days |
|
4.Specification of chain bucket dredging salt ship,YS-WYC80
Item |
Parameters |
Material |
Quantity of Bucket |
50 pieces |
|
Hull Body(L W H) |
1800cm×150cm×90cm |
|
Main Frame |
2.8cm×1.1mX1.1m |
|
Buckets Ladder |
1250cm×0cm×45cm |
|
Four corner-wheel |
Dia-90cm Width-75cm |
|
Salt capacity |
80m3/h |
|
Dredging Depth |
6m |
|
Chain |
67cm×90cm×20mm |
|
Bucket |
Capacity:0.065m³, |
35kg/piece |
Reducer |
650×1set,350×1set,250×2set |
|
Power |
46KW |
|
Waranty |
1 year |
|
Lead Time |
15 working days |
|
Yong Sheng shipyard have 3 factories in Qing Zhou city,China,we are the biggest and specialized OEM of sand-digging machinery,sand making machinery, dredging machinery, mineral processing machinery in ShanDong,China.our senior engineer and professional R & D staff can rapidly works out the reasonable and feasible plan according to your job site and your requirement.
5. small chain bucket dredging salt ship
