Help CenterDredge Machine Cleaning Mud With Water Flow 3000m3/h to Venezuela
Related Products
-
14inch Cutter Head Suction DredgerNegotiableMOQ: 1 Set -
Chain Bucket Sand Dredger to Dig Sand or StoneUS$ 80,000 - 210,000MOQ: 1 Sheet
-
River Sand Choose Iron Ship With Magnetic Seperators and ISO9001,CE CertificationUS$ 100,000 - 300,000MOQ: 1 Set
-
China Cutter Suction DredgerUS$ 250,000 - 290,000MOQ: 1 Set
-
River Digging Sand DredgerUS$ 200,000 - 1,500,000MOQ: 1 Set
Specifications
This dredger is designed for client from Venezuela.We can provide ZC,CCS certification.FEATURES
1) Completely assembled and fully tested before delivery
2) Simple, rapid assembly and dismantling
3) Standard design, allowing early delivery and low price
4) Spare parts available from stock
5) Free for one set of spare parts
6) Can be delivered to any location where need dredging
7) Responsible for installation and training of operators in the dredging place
8) Transportable by road, rail or sea
9) Reliable engine capability , dredging pump capability and hydraulic system
10) Fresh water engine cooling system
11) Efficient fuel consumption
12) One-man operate dredger by Programmable Logic Controller ( PLC system )
13) Airconditioning – Vessel Standard equipment
14) Wide range of optional equipment available
- GENERAL
No. | Item | Specification |
1 | Total Length (with ladder raised) approx | 35m |
2 | Length over pontoons | 26.00m |
3 | Breadth | 7.2m |
4 | Depth | 1.90m |
5 | Main pontoon | 18.00m × 3.50m × 1.90m |
6 | Side pontoon | 26.00m × 1.70m × 1.90m |
7 | Mean draught with full bunkers approx | 1.5m |
8 | Maximum standard dredging depth | 16.00m |
9 | Dredge pump water flow capacity | 3000m3/h |
10 | Standard discharge distance | 1500m |
11 | Cut Width @ Maximum digging depth | 35m |
12 | Cut Width @ Minimum digging depth | 44m |
2. Marine Diesel Engine to drive dredger pump
Item | Main Diesel Engine |
Manufacturers | JICHAI ENGINE |
Model | 8190 |
Continuous Power | 720kw@1450rpm |
Amount | 1 Set |
Marine Diesel Engine to drive hydraulic system
Item | Main Diesel Engine |
Manufacturers | Cummins Engine |
Model | KTA |
Continuous Power | 261kw@1800pm |
Amount | 1 Set |
3. Marine Generator / Generator set
Item | Main Generator | Standby Generator |
Manufacturers | Lanzhou Electric Motor Co.,Ltd | WEICHAI Power CO.,LTD |
Power | 24kw@1450rpm | 24kw@1450rpm |
Amount | 1 Set | 1 Set |
4. Dredge Pump
Item | Parameters | Note |
Made | Warman Technology, Australia | SHIJIAZHUANG PUMP GROUP |
Type | 350G-H | Professional Dredge Pump |
Capacity | 3000m3/h |
|
Head | 65 m |
|
Speed | 400—550 r/min |
|
Efficiency | 74—78% |
|
NpSHr | <4.5 m |
|
Pump Suction Diameter | 400 mm |
|
Pump discharge Diameter | 350 mm |
|
Max.Diameter of Flowed Partice | 201 mm |
|
