river small sand dredger
- 0 per Month
- TianJinPort
- T/T
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
- 2018 Hot newest small 1000m3 Sand Cutter Suction Boat
- Customized small 12 Inch cutter suction river dredging equipment
- 2022 Hot Newest Small 1200m3 Cutter Suction Dredger Manufacturer Sand Pump Suction Dredger Sand Dredging High Gold Recovery Rate
Product Details
Condition: | New | Type: | Cutter Suction Dredger | Place of Origin: | Shandong, China |
Brand Name: | YongSheng | Model Number: | CSD-250 | Dredging Depth: | 9m |
Product Description
Specifications
1.Ensure quality2.We can design product as your request
3.Timely delivery
4.Simple assembly
5.Welcome to our shipyard
Qing Zhou Yong Sheng Dredging Machinery CO.,LTD
1.small cutter suction dredge
2.Max dredging depth 8m, discharge distance1-2km
3.small sand dredge,small dredge vessel
1.small dredge OEM Service
The dredger we produce is self-propelled or non self-propelled,portable cutter suction dredger. The hull uses dismantle and box-like structure, which equipped with horizontal shifting devices, cutter ladder lifting devices, spud devices, deck crane and so on. It can also be equipped with anchoring poles and trolley devices. Generally, it has functions on dredging, conveying and discharging of mud or sand. It can produce certain amount of vacuum by the centrifugal pump.
Product have been audited by Bureau Veritas
2.Our Team- -Do Product well ,At a high point
Qingzhou Yongsheng Sand-digging Machinery Co., Ltd. established in 1990, Over years of development, the company has been the largest production center of cutter suction dredgers, sand mining machinery and gold dredging machinery in China.
To enlarge production, we have built 4 shipyard in different area of China ,owns blanking workshop, gold panning machinery processing workshop,mining salt Machinery workshop, anti-corrosion workshop, general assembly workshop, product debugging and testing center before ex-factory.
Our cutter suction dredgers have passed ISO9001 ,CE ,Bureau Veritas,and Chinese Classification Management System Certification with good quality and low price.
And we belive that our senior engineer and professional R & D staff can rapidly works out the reasonable and feasible plan according to your job site and your requirement.
3.Specification
SPECIFICAITON OF YS-CSD-250 (dredging depth 10m) | |
Items | Specs |
Total Length | 25m |
Hull Length | 18.0m |
Hull depth | 1.6m |
Hull width | 5.2m |
Main Power | 450KW |
Auxiliary Engine | 24KW HYDRAULIC SYSTEM |
Pump model | WN-250 |
Pump Suction Dia | 300mm |
Pump Discharge Dia | 250mm |
Dredging Depth | 10m |
Water flow | 1200m^3/h |
Discharge Distanc | 1000m |
Working weight | 100T |
Spuds | 377mm Two sets |
Winches | 3 Sets |
Operation System | The most advanced Hydraulic and PLC control system |
Spare parts | Tools for disel,oil seal,welders ect 70 items. |
Delivery Time | 80days |
4. Small Sand Dredge from Qingzhou Yongsheng digging Machinery Co., Ltd,
more details pls see the pictures below
IF YOU HAVE ANY QUESTION ,PLEASE DON'T HESITATE TO TELL US ACCORDING TO THE ABOVE CONTACT INFORMATION,WE WILL SOVE THE QUESTION FOR YOU IN PATIENCE !
