River sand cutter suction dredger

No.

Item

Specification

1

Total Length  (with ladder raised) approx

35m

2

Length over pontoons

25.00m

3

Breadth

7.2m

4

Depth

1.90m

5

Main pontoon

18.00m × 3.50m × 1.90m

6

Side pontoon

25.00m × 1.850m × 1.90m

7

Mean draught with full bunkers approx

1.3m

8

Maximum standard dredging depth

15.00m

9

Dredge pump water flow capacity

3000m3/h

10

Standard discharge distance

1500m

11

Cut Width @ Maximum digging depth

35m

12

Cut Width @ Minimum digging depth

44m

Item

Main Diesel Engine

Manufacturers

JICHAI ENGINE

Model

8190ZLCZ-R

Continuous Power

720kw@1450rpm

Amount

1 Set

Item

Main Diesel Engine

Manufacturers

                  WEICHAI

Model

ZCW-6160

Continuous Power

270kw@1000pm

Amount

1 Set

Item

Parameters

Note

Made

Warman Technology, Australia

SHIJIAZHUANG  PUMP GROUP

Type

350G-H

Professional Dredge Pump

Capacity

3000m3/h

Head

65 m

Speed

400—550 r/min

Efficiency

74—78%

NpSHr

small than 4.5 m

Pump Suction Diameter

400 mm

Pump discharge Diameter

350 mm

Max.Diameter of Flowed Partice

201 mm

Solid Capacity

           450m³/h

Count 15% solid
