Specifications
1. Advanced PLC system2. Reliable hydraulic system
3. Reasonable stucture and top parts' quality in china
4. Quick delivery
Features:
1. One-man operation. The most advanced PLC control system.
2. New highly effective cutter/wheel drive system
3. Reliable hydraulic system.
4. Fresh water cooling system
5. Completely assembled and fully tested before delivery
6. Very simple and fast assembly, afloat of onshore
7. Standard design, allowing short delivery times
8.Standard spare parts available from stock
9.Designed as standard to qualify for Coastal Waters Certificate
10.Optional equipment available
Items | Specs | Remarks |
Total Length | 21.m |
|
Body Length | 14.0m |
|
Hull depth | 1.6m |
|
Hull width | 4.6m |
|
Main Power | 300KW WeiChai Diesel Model,6160, | Pump Power |
Auxiliary Power | 24KW |
|
Pump model | WN200 Suction10" Discharge8" | Shijiazhuang |
Suction Pump Dia | 250mm |
|
Discharge Pump Dia | 200mm |
|
Water flow | 800-1000m³/h(Capacity-min 100M3) |
|
Discharge Distance | 1500m (Maximum ) |
|
Total max weight when working | 40T |
|
Spuds | 325mm Two sets (Hydraulic) | 12 metre |
Winches | 2 Sets for horizontal movement, one for ladder |
|
Cylinder | Two Hydraulic Cylinders |
|
Operation System | PLC Hydraulic System |
|
Operating Cabin | With air condition. All the operating system with English description. |
|
Dredging depth | 1-9m |
|
|
|
|
|
|
|
Spray-paint | 3 layers,Anti rust guarantee 1 year |
|
