hot sell resistant fiberglass mesh
- 100000 Square Meter / Square Meters per Month
- TIANJIN
- T/T L/C Credit Card
Product Details
Place of Origin: | Hebei, China | Brand Name: | weihao | Model Number: | FG60g-300g/m2 |
Application: | Wall Materials | Weight: | 60,75,90,110,125,145,160g/m2 | Width: | 1m,25cm |
Mesh Size: | 4x4,5x5,10x10mm | Weave Type: | Plain Woven | Yarn Type: | C-Glass |
Alkali Content: | Medium | Standing Temperature: | 300 |
Product Description
Specifications
1)Pass CE,ETAG,ITB,ISO2)Help clients avoid anti-dumping duty
3)Acrylic coating 16-20%
4) Platinum glass fiber yarn
Specifications
1)Pass CE,ETAG,ITB,ISO
2)Help clients avoid anti-dumping duty
3)Acrylic coating 16-20%
4) Platinum glass fiber yarn
Fiberglass mesh fabric, is woven by platinum fiberglass yarn, and then coated by acrylic glue. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, bitumen, gypsum waterproof and so on.
Fiberglass mesh fabric high quality ability:
1) straight warp and weft of mesh & bright surface.
2) Coating enough alkaline resistant glue and keep 60% - 80% strength after testing in Naoh 28 days later
3) Made by C-glass fibers woven roving as basis material, and then treated with acrylic acid copolymer liquid, glue content:14-18%
4) High tensile strength so the mesh is not easily teared.
5) free for small sample
6) OEM service is provided
Fiberglass mesh fabric Main specs:
plain weave :
5mm x 5mm/75g/m2, 90g/m2, 125g/m2, 145g/m2, 160g/m2,etc.
4mm x 4mm/75g/m2, 90g/m2, 110g/m2,125g/m2, 135g/m2, 145g/m2, 160g/m2, etc.
10mm x 10mm/90g/m2, 110g/m2, 125g/m2, 135g/m2. 145g/m2, 150g/m2,160g/m2,etc.
2.85mm x 2.85mm/60g/m2, 75g/m2,etc
10X20mesh/inch:60g/ m2,etc
Certificates:
We pass ISO9001:2000, ITB and Europe ETAG004 certificate.
Fiberglass mesh fabric Technical Data
NO. | Main Specifications | Mesh size | Yarn density | Mass | Tensile strength | |||
warp | weft | warp | weft | warp | weft | |||
1 | 4×4-75g/m2 | 4 | 4 | 48/2 | 200 | 75±3 | 700 | 850 |
2 | 4×4-90g/m2 | 4 | 4 | 67/2 | 200 | 90±3 | 950 | 1100 |
3 | 4×4-145g/m2 | 4 | 4 | 134/2 | 240 | 145±5 | 1500 | 1500 |
4 | 4×4-160g/m2 | 4 | 4 | 134/2 | 300 | 160±5 | 1500 | 1650 |
5 | 4×5-110g/m2 | 4 | 5 | 100/2 | 360 | 110±5 | 1100 | 1200 |
6 | 4×5-125g/m2 | 4 | 5 | 100/2 | 280 | 125±5 | 1200 | 1300 |
7 | 4×5-145g/m2 | 4 | 5 | 134/2 | 300 | 145±5 | 1400 | 1400 |
8 | 4×5-160g/m2 | 4 | 5 | 134/2 | 360 | 160±5 | 1500 | 1600 |
9 | 5×5-90g/m2 | 5 | 5 | 67/2 | 240 | 90±3 | 950 | 1150 |
10 | 5×5-125g/m2 | 5 | 5 | 100/2 | 340 | 125±5 | 1100 | 1300 |
11 | 5×5-145g/m2 | 5 | 5 | 134/2 | 360 | 145±5 | 1450 | 1600 |
12 | 5×5-160g/m2 | 5 | 5 | 134/2 | 430 | 160±5 | 1500 | 1700 |
13 | 10×10-90g/m2 | 10 | 10 | 200/2 | 300 | 90±3 | 900 | 1200 |
14 | 10×10-110g/m2 | 10 | 10 | 250/2 | 450 | 110±5 | 1000 | 1400 |
Packing
Inner packing: shrink film packing one roll ,then 30 to 60 rolls/pallet or 4 rolls/carton
Contact Us
- Anping Weihao Hardware Wire Mesh Products Co., Ltd.
- Contact namelisa xu
- Phone86-318-7800022
- AddressWire Mesh Industrial Zone, Anping , Hebei Hengshui,Hebei
