Help CenterFiberglass Mesh for Waterproofing
US$ 0.03 - 0.16
MOQ: 1000 Square Inches
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
WEIHAO
Model Number:
wh
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Heat Preservation Fiberglass MeshUS$ 0.03 - 0.16MOQ: 1000 Square Inches -
Anti-Alkali Fiberglass MeshUS$ 0.03 - 0.16MOQ: 1000 Square Inches
-
Bullpen Fence/Ranch FenceUS$ 3 - 3MOQ: 1 Meter
-
Hot-dipped Galvanized Bullpen FenceUS$ 3 - 3MOQ: 1 Meter
-
Bullpen Fence/Sheep Wire Mesh FenceUS$ 3 - 3MOQ: 1 Meter
Place of Origin
Hebei, China
Brand Name
WEIHAO
Model Number
wh
Application
Wall Materials
Weight
60g/m2-300g/m2
Width
1M
Mesh Size
5*5mm, 6*6mm, 10*10mm
Weave Type
Plain Woven
Yarn Type
C-Glass
Alkali Content
Medium
Standing Temperature
500
Product Description
1,Material: | C-Glass,E-Glass woven fabric etc. | |||
| 2,Coating: | Alkaline-resistance resin. | |||
| 3,Mesh Size: | 3X3mm,4X4mm,4X5mm,5X5mm etc. | |||
| 4,Size: | Width:0.3-2.0m Length:300m,100m,50m,500m etc. | |||
| 5,Weight: | 45g/m2-500g/m2 | |||
| 6,Color: | Regular White,Blue,Yellow or customized. | |||
| 7,Packaging: | 1pc/boxing or special requirement etc. | |||
| 8,MOQ: | 15000m2/type etc. | |||
| 9,Sample: | Free small sample by freight collect. | |||
| 10, Produce time: | Sample time:within 1 days etc. Mass products time:28-35 days etc. (details according to the produce line row.) | |||
Characters of fiberglass mesh
High strength, high modulus, light weight.
Good dimensional stability, stiffness, smooth, not easy to shrinkage deformation, good positioning.
Good impact resistance. (Due to the high intensity and toughness)
Anti mildew and insect.
Fire protection, thermal insulation, sound insulation.
Specification of fiberglass mesh
| Item Number | Yarn(Tex) | Mesh(mm) | Density Count/25mm | Finish Weight(g/m2) | Tensile Strength × 20cm | Woven Structure | Content of resin%(≥) | ||||
| Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | ||||
| 5x5-70 | 45×2 | 200 | 5 | 5 | 5 | 5 | 70 | 550 | 850 | Leno | 16 |
| 5x5-80 | 67×2 | 200 | 5 | 5 | 5 | 5 | 80 | 700 | 850 | Leno | 16 |
| 5x5-90 | 67×2 | 250 | 5 | 5 | 5 | 5 | 90 | 700 | 1050 | Leno | 16 |
| 5x5-110 | 100×2 | 250 | 5 | 5 | 5 | 5 | 110 | 800 | 1050 | Leno | 16 |
| 5x5-125 | 134×2 | 250 | 5 | 5 | 5 | 5 | 125 | 1200 | 1300 | Leno | 16 |
| 5x5-135 | 134×2 | 300 | 5 | 5 | 5 | 5 | 135 | 1300 | 1400 | Leno | 16 |
| 4x4-135 | 100×2 | 250 | 4 | 4 | 6 | 6 | 135 | 1000 | 1300 | Leno | 16 |
| 5x5-145 | 134×2 | 360 | 5 | 5 | 5 | 5 | 145 | 1200 | 1300 | Leno | 16 |
| 4x5-150 | 134×2 | 300 | 4 | 5 | 6 | 5 | 150 | 1300 | 1300 | Leno | 16 |
| 5x5-160 | 134×2 | 400 | 5 | 5 | 5 | 5 | 160 | 1450 | 1600 | Leno | 16 |
| 4x4-160 | 134×2 | 300 | 4 | 4 | 6 | 6 | 160 | 1550 | 1650 | Leno | 16 |
| 4x5-165 | 134×2 | 350 | 4 | 5 | 6 | 5 | 165 | 1300 | 1300 | Leno | 16 |
Our Services
1. Reasonable price, best quality.
2. 24 hours on-line service, efficient and convenient after-sale service.
3. We have our own factory and can provide the direct price.
Company Profile
| Business Type: | Manufacturer, Trading Company | |
|---|---|---|
| Recent Transactions: | 1 | |
| Main Products: | Razor Barbed Wire,Welded Wire Mesh,Drywall Screw,Galvanized Hexagonal Wire Mesh,Hot galvanized wire | |
| Location: | Hebei, China (Mainland) | |
| Year Established: | 2010 | |
| Year start exporting: | 2007 | |
| Number Of Employees: | 51 - 100 People | |
| Total Revenue: | US$10 Million - US$50 Million | |
| Main Markets: | Mid East, South Asia, South America, Eastern Europe, Eastern Asia | |
| Average Lead Time: | 15 Day(s) |
Anping Weihao Hardware Wire Mesh Products Co., Ltd. is a modern company engaged in wire mesh, metal wire and wire processed products. We can also supply various wire mesh machines. Our main products are classified into three categories. Razor Barbed wire,Wire Mesh Series, Barbed Wire, Galvanized Steel Wire, Hot-dip Galvanized Wire, Electra Galvanized Wire, Black Iron Wire, Annealed Wire, Cut Wire, U Type Wire, PVC Coated Wire, Brass Wire, Stainless Steel Wire, and Stainless Steel Fine Wire. Our products sell well in China. In order to further develop the market, we have export to America, Germany, Israel and other countries and regions since 2001. With competitive prices, good reputation and prompt delivery, we have established regular business relationship with many foreign customers. We will continue to keep our principle of offering quality products and satisfactory services for customers. We welcome you to contact us. |
