Steel Grating is made by Carbon or mild steel of certain sizes through the processing of slit
cutting, serration-making, press welding, inspecting before galvanization, galvanizing,
checking before packing, etc.
| No | Item | Description |
| 1 | Bearing bar | 25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,.....75x10mm |
| 2 | Bear bar pitch | 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40,41,60mm. US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x 1/4", 1 1/4"x 1/4", 1 1/2"x 1/4" etc. |
| 3 | Cross bar pitch | 38,50,76,100,101.6mm |
| 4 | Material | Q235,A36,SS304 |
| 5 | Surface treatment | Black, hot dipped galvanising, paint |
| 6 | Standard | China: YB/T 4001.1-2007 |
| USA: ANSI/NAAMM(MBG531-88) | ||
| UK: BS4592-1987 | ||
| Australia: AS1657-1985 |
Steel product standard: China YB/700-88
Features: manufactured according to customers' requirements
For example:
1) Bearing bar pitches may be 12.5, 15 to 30, 40, 60, 80 and 90mm; of which 30
and 40mm are recommended
2) Cross bar pitch may be 30, 38, 50, 76 and 100mm; of which 50 and 100mm are
recommended
3) Advantages of steel grid planks: light weight, strong intensity, big load capacity,
transmission and aeration, anti-skid and secure, wears well, non-sagging,
non-dirt, and easy to install
4) Hot galvanizing standard: China GB/T13912-92
5) Wrapping: wrapping is as requested by customers, or depends on the wrapping
Using:
1. Reasonable price, best quality.
2. 24 hours on-line service, efficient and convenient after-sale service.
3. We have our own factory and can provide the direct price.
Q: What are we doing?
A: We offer the best goods with the right price, make the best ones on our own
factory, and also offer sourcing service for many products.
Q: What are we making in our own factory?
A: We are one of the best suppliers in China. We own and co-own several factorys, so
we have many exclusive products that is only available from us.
Q: If our MOQ is as high as the factories?
A: Based on strong sales network and stable quality, we can sell a huge stock in a
short time. For the best selling products, we keep a wide stock on them. So we can
offer many products with a very low MOQ. This is not comparable for the factories.
Q: How is customer service?
A: All our sales representatives can speak fluent English. They will answer all of
your questions within 12 hours.
