China Metal Pallet Racking / Storage Warehouse Steel Rack

Name: China Metal Pallet Racking / Storage Warehouse Steel Rack
Brand: REACH
SKU: 143463208
Availability: InStock

US$ 168 - 178 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

REACH

Model Number:

RQ9636

Ningbo Reach Imp & Exp Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Port /Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name REACH

Model Number RQ9636

Type Beam Rack

Scale Heavy Duty

Capacity 200-1500kg

Product Description

1. Features of warehouse storage pallet rack system:	1) Beam levers are adjustable in 75mm pitch interval. 2) Different sizes, various specifications and colors are available according to your needs. 3) Maximizes space utility ratio while retaining optimum product accessibility. 4) Strength and rigidity prevents compression damage to goods. 5) Bottom level of pallets can be stored on the floor, lowering structure costs.
2. Material:	High grade Q235B Cold Rolled Steel
3. Surface treatment:	High-quality Powder Coating Finishing.
4. Load Capacity & Dimension:	Loading capacity: 200-5000 kg/beam level. Height: 1500-10000mm Depth: single row 800-1200mm ( decided by pallet size), back-to-back 1900-2700mm Length: 2300/2400/2500/2700/3300/3900 (2 or 3 pallets per level, according to pallet size) Special sizes also available to specific storage needs.
5. Main Parts Specs:	1) Uprights 2) beams 3) Horizontal & diagonal bracings, upright footplates, safety locking pins, bolts & nuts, anchors and all necessary components.
