Computer Beam Saw
Model: MJK260
Patent No: 01213655.7
We are the professional manufacture of woodworking machine since 1991 years, now we become one of the most famous manufacture and exporter in China.
Pre-sales Service:
a.We can give you professional solution according your requirement.
b.Once we sign the contract, We will send you the picture of the machine and package for your confirmation after we finish the machine, At the same time. we will also help you arrange shipment.
After-sales Serivce:
a. If you need our engineer go to install machine, You should pay the return ticket ,local hote,food. we provide 7 days for free
b. If you have any question or problem with the machine, you can send us the picture with the problem parts by email, we can answer you within 24 hours
model | K260 | K320 | K380 | |
total weight | 2500KG | 3000KG | 3800KG | |
working table size | 2600MM | 3200MM | 3800MM | |
machine size(LXW) | 3400MM×5230MM | 3400MM×5830MM | 3400MM×6430MM | |
working pressure | ≥6KG/CM2 | ≥6KG/CM2 | ≥6KG/CM2 | |
working voltage | 380V3phase 4lines | 380V3phase 4lines | 380V3phase 4lines | |
main motor power | 7.5KW | 7.5KW | 7.5KW | |
scoring saw motor power | 1.5KW | 1.5KW | 1.5KW | |
driving power | 1.5KW | 1.5KW | 1.5KW | |
saw blade projection height | ≤80MM | ≤80MM | ≤80MM | |
cutting length | 2440MM | 3050MM | 3660MM | |
cutting speed | 3-30M/MIN | 3-30M/MIN | 3-30M/MIN | |
lineal cutting precision | 0.20MM/2440MM | 0.20MM/2440MM | 0.20MM/2440MM | |
electrics | PLC | |||
driving mode | chain | chain | chain | |
speed adjust | transducer | transducer | transducer | |
feeding rack | roller( or plane surface) | roller( or plane surface) | roller( or plane surface) | |
positioning mode | manual | manual | manual | |
main saw size | outter diameter | φ350MM | φ350MM | φ350MM |
inner diameter | φ30MM | φ30MM | φ30MM | |
thickness | 4.4MM | 4.4MM | 4.4MM | |
scoring saw size | outter diameter | φ180MM | φ180MM | φ180MM |
inner diameter | φ30MM | φ30MM | φ30MM | |
thickness | 4.3/5.3MM | 4.3/5.3MM | 4.3/5.3MM | |
main saw rotation | ≈5000rpm | ≈5000rpm | ≈5000rpm | |
scoring saw rotation | ≈7000rpm | ≈7000rpm | ≈7000rpm | |
