woodworking panel saw
Model: MJ6132TD
We are the professional manufacture of woodworking machine since 1991 years, now we become one of the most famous manufacture and exporter in China.
if you want to test the performance of machine ,we can sent sample to you with cost offer .
Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
After-sale Service:
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Engineers available to service machiner overseas
Model(manual control) | MJ6132TD |
Dimension of sliding table | 3200*375mm |
Gross cut capacity | 3200mm |
Width of cut between saw blade and rip fence | 1250mm |
Saw blade diameter | 300mm(250-300mm) |
Height of cut (300mm) | 70-80mm |
Speed of main saw spindle | 4500/6000rpm |
Main spindle diameter | 30mm |
Tilting saw blade | 0-45 and 90° |
Main motor | 5.5kw(7.5HP) |
Scoring saw blade diameter | 120mm |
Speed of scoring saw blade | 8000rpm |
Scoring saw diameter | 20mm |
Scoring motor | 1.1kw (1.5HP) |
weight | 850kgs |
Packing size for machine body(L*W*H) | 2200*1150*1100mm |
Packing size of sliding table | 3350*480*320mm |
