Home > Products > Woodworking Sanding Machine > R-RP1300 woodworking wide belt wood floor/wood door sander machine
R-RP1300 woodworking wide belt wood floor/wood door sander machine
- 200 Unit / Units per Month
- QINGDAO
- T/T
Product Details
Condition: | New | Type: | Sander | Place of Origin: | Shandong, China |
Brand Name: | LEADER | Model Number: | R-RP1300 | Voltage: | 380V |
Dimension(L*W*H): | 2600*2190*2200mm | Certification: | CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Woodworking wide belt wood floor/wood door sander machine
Model: R-RP1300
Model | BSG400 | BSG630 | BSG1000 | BSG1300 |
Working width | ≤630mm | ≤630mm | ≤1000mm | ≤1300mm |
Working thickness | 3-80mm | 3-120mm | 3-120mm | 3-120mm |
Feed speed | 6-30m/min | 6-30m/min | 6-30m/min | 6-30m/min |
Size of abrasive belt | 650*1780mm | 650*1780mm | 1030*2200mm | 1330*2200mm |
Total power | 10.97kw | 20.37kw | 38.87(27.87)kw | 63.37(56.37)kw |
NO.1 abrasive belt motor | 5.5kw | 11kw | 22(15)kw | 37(30)kw |
NO.2 abrasive belt motor | 4kw | 7.5kw | 15(11)kw | 22kw |
Conveyor belt motor | 1.1kw | 1.5kw | 1.5kw | 4kw |
Lifting motor | 0.37kw | 0.37kw | 0.37kw | 0.37kw |
Working air pressure | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa |
Consumption of compressed air | 0.5m³/min | 0.5m³/min | 0.5m³/min | 0.5m³/min |
Overall dimensions(L*W*H) | 1200*1600*2200mm | 1200*1600*2200mm | 1780*1800*2200mm | 2600*2190*2200mm |
Specification:
1.The machine adopts welded steel,after quenching,good stability.Imported conveyor belt,good reliability,durability.
2.The series uses the beam barrel and the beam seat structure,good stability,convenient maintenance.
3.Belt tensioning cylinder adopts cast iron processing,tensile strength is great,good stability.Conveyor belt adjusting cylinder adopts 63×20 cylinder.large power,good stability.
4.Active roll stigmas are bold,and after quenching,ensure the stability and durability of the driving roller.
5.Thickness displaying table using photoelectric sensing head,high precision,good stability under complex environment.
We are the professional manufacture of woodworking machine since 1991 years, now we become one of the most famous manufacture and exporter in China.
If you want to test the performance of machine ,we can sent sample to you with cost offer .
Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
After-sale Service:
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Engineers available to service machiner overseas
