2017 Most Popular 540 Pto Gearbox With Long-term Service

2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-1
2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-2
2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-3
2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-4
2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-5
2017 Most Popular 540 Pto Gearbox With Long-term Service thumbnail-6
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-1
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-2
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-3
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-4
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-5
2017 Most Popular 540 Pto Gearbox With Long-term Service photo-6
US$ 150 - 180 MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GTM
Model Number:
LHRC-B-1
Contact Supplier Request Quote Chat Now
Zhejiang Hongye Agricultural Equipment Science And Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GTM
Model Number LHRC-B-1
Gearing Arrangement Bevel / Miter
Output Torque 0.2-0.4Nm before asssembly oil seal
Rated Power 8-120HP
Input Speed 600rpm
Output Speed 458rpm



2017 most popular 540 pto gearbox With Long-term Service



2017 most popular 540 pto gearbox With Long-term Service

Product Description

Product details

Housing Material QT450
Gear Shaft Material 20CrMnTi
Ratio 1.31:1
Input speed 600 rpm
Teeth 16/21
Color Customer Requests
Backlash 0.25-0.46
Mould NO. 7
Noise 85db-1meter
Weight 56.3kg
Product Keywords 540 pto gearbox


Quality assurance:

5 years for quality assurance



2017 most popular 540 pto gearbox With Long-term Service2017 most popular 540 pto gearbox With Long-term Service2017 most popular 540 pto gearbox With Long-term Service2017 most popular 540 pto gearbox With Long-term Service

Company Information

ABOUT US

Zhejiang Hongye Agricultural Equipment Science and Technology LTD was established in 1995, located in economic development zone of Wenling city, southeast of China. Hongye commits itself to development, production, sales and service for transmission products. Its products include spiral and straight bevel gearbox, cylinder gear speed reducer, worm reducer, and transmission case etc, widely used in various fields as lawn mowers, grain transportation and storage equipments, rice harvesters, corn harvesters, rotary tillers, pesticide sprayers, fertilizer spreaders, potato harvester, post-hole diggers, snow-blowers, garden machines and oil exploitation fields, etc, with the annual quantity over 250,000pcs.

2017 most popular 540 pto gearbox With Long-term Service
Related Products
2017 most popular 540 pto gearbox With Long-term Service

Factory manufacturing grain transporation gearbox

2017 most popular 540 pto gearbox With Long-term Service

RG series agricultural rotary lawn mower gearbox

2017 most popular 540 pto gearbox With Long-term Service

Long life-span agricultural short harvester reversing gearbox

2017 most popular 540 pto gearbox With Long-term Service

agricultural grain auger gearbox with shafting fork



Certifications
2017 most popular 540 pto gearbox With Long-term Service

security guaranteed 100%

Protect Your Payment, Secure Your Order

Contact Us
2017 most popular 540 pto gearbox With Long-term Service

Mob:+86 15058639993
Skype:honeyhoney5122
QQ: 565517637
Wechat: A132589888
Whatsapp: +86 15058639993



2017 most popular 540 pto gearbox With Long-term Service



Type Ratio Input rpm Output rpm Output Torque Power
LHRC-B-1 1.31:1 600rpm 458rpm 1842 NM 80-120 HP





FAQ

FAQ

01

Are you trading company or manufacturer ?

We are manufacturer and also can export by ourselves.



02

How long is your delivery time?

Generally it is 10-15 days if the goods are in stock including confirming all the technical details. or it is 30-45 days if the goods are not in stock, it is according to new design.



03

Do you provide samples ? is it free or extra ?

Yes, we could offer the sample as customer's request for certain charge as the drawing shows.



04

What is your terms of payment ?

Payment<=5000USD, 100% TT payment in advance. Payment>=10000USD, 30% T/T in advance ,balance before shippment. We also accept LC, WU payment.



05

Can you deal with OEM & ODM order?

Yes. Hongye offers our customers with customized services from drawings.




06

Where is your company address?

Our company hongye located in NO.5 of Changjiang Road,2nd Economic Development Zone of Wenling Zhejiang China.
