Boton Multi-Leaf Spring Wave Spring (Motorcycle Parts)

Wuhu Boton Automobile Parts Factory is a professional thermostat manufacturer. We specialize in producing four series of products: Bimetal thermostatic coil and disc, heating chambers for engine carburetors, auto generator regulars, various auto glass lifter motor protectors.

Bimetal thermostat consists of two metallic strips ,and this part being adjusted the angle causing movement by the hotter temperature ,when heated up ,it bends in a pre-determined manner, and can be used to monitor, measure and regulate temperature.

Its main application are in thermostats for heating chamber or fan clutch, but they are also used in control devices for instance in automobiles.

1) The thermostats that are used in refrigerator, household conditioner, car-conditioner,
cold-storage, water dispenser, electricity heating device, washing machine.
2) The rigid producing and checking rules and the technologically mature procedures
ensure the reliability and performance of thermostats, which will meet the higher
needs of clients.

3) Certificate: ISO 9001:2000

Thermostatic bimetal functions:

The effects of thermostatic bimetal curvature in response to a change in temperature are utilized in practical applications to achieve different aims. These can essentially be described by the following functions :measuring, limiting,controlling,compensation,pulse-generation,retardation.All these functions overlap to a certain extent so that a particular application may fall under several categories .

Measuring

Temperatures and certain electrical variables and their rate of change can be regulated by calibrated systems.

Examples:

Spiral thermometers, Ammeters

Limiting

Trip functions are required at certain upper or lower limits in order to initiate or to cut out an operation.

Examples :

Automatic circuit breakers

Motor protection switches

Controlling

Within a certain range,functions are cut in or out ,or circuits made or broken,in order to maintain a certain average setting.

Examples:

Electric iron controls, Bypass valves

Compensation

A deviation from the initial condition is compensated for by the thermostatic bimetal action.

Examples :

Color television tube compensation,Measuring instruments with compensation for fluctuations in ambient temperature.

Pulse-generation

An operation is triggered at clocked intervals.

Examples:

Flasher relays, Hotplate heating coils

Retardation

An incoming signal (e.g. current)will only trigger an operation after a defined delay period.

Example:

Thermal relay

Our marketing:

overseas:BMW;AUDI;BENZ;NISSAN;TOYOTA;MITSUBISHI;HONDA;ISUZU;STEYR

domestic:No.1,No2, Brilliance Group, Jiang steam, Beiqi Fukuda, Baoding-greatwall,Cherokee,steyr , Yuchai, Isuzu

Characteristics:

Stable performance, high accuracy, small size, lightweight, high reliability, long lifespan, less interference to radio

Material information (TB208/110)

Testing Method

Package:

Thanks for your reading . Have a nice day !
