Home > Products > Duct Machinery > Metal Seam Welder
Metal Seam Welder
- 0 per Month
- T/T
You May Like
Product Details
| Brand Name | Chengyang | Model Number | FN-35 | |
| Certification | CE | Condition | New |
Product Description
1.Cross seam,horizontal and vertical seam;
2.Fast speed and high efficiency;
3.According to the clients demand we set the function of continuous weld and pulse weld;
4.Equipped with a high reliability control box;
5The welding speed can be regulated continuously;
6Suitable for the site of welding airproof veses.
Main parameters:
Item Type | FN-35 | FN-55 | FN-75 | FN-100 |
Rated input capacity | 35KVA | 55KVA | 75KVA | 100KVA |
Rated input voltage | 1-380V/50HZ | 1-380V/50HZ | 1-380V/50HZ | 1-380V/50HZ |
Rated load cycle | 50% | 50% | 50% | 50% |
Max.input capacity | 45KVA | 88KVA | 110KVA | 170KVA |
Max.short circuit current | 6200A | 11000A | 16000A | 26000A |
ure of electode | 400KGF | 600KGF | 1000KGF | 1000KGF |
The flow of cooling water | 6L/min | 6L/min | 8L/min | 8L/min |
Arm length | 600mm | 600mm | 600mm | 600mm |
Electrode journey | 80mm | 80mm | 80mm | 80mm |
Speed of welding | 0.5-3m | 0.5-3m | 0.5-3m | 0.5-3m |
Weight | 220kg | 280kg | 350kg | 400 |
