Place of Origin Chongqing, China
Brand Name DENEL/LIYANG
Model Number 12N9-4B

Specifications

1.Model.12N9-4B
2.Voltage:12V
3.Capacity:9Ah/10hr
4.Size:136*76*139mm
4. Certificates:CE,TS16949:2009,ISO9001:2008

12N9-4B  Good Quality Dry Charged Motorcycle Battery  For Street Motorcycle SL125-5



12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5







1.PRODUCT INFORMATION:



Battery type Voltage
(V) 		Capacity
(10H-R)
(AH) 		Dimensions
(L*W*H)
(MM) 		Weight
(W/O Acid)
(KG) 		Terminal type Acid weight
(kg) 		Regular charge current
(A)
12N9-4B 12 9 136*76*139 2.1 B 0.85 0.5



2.FEATURES:

1) Good start-up capability:

It can output the high electric power instantly which brings the motorcycle superior starting effect. Motorcycle can start up in one touch.

2) Starting performance on the condition of low temperature:

Unique alive materials species makes well starting-up on of motorcycle under condition of low temperature.

3) Lower resistance:

Infinitesimal resistance interior material assures sufficient power output.

4) Lower self-discharging rate:

Introduction of special fitted lead powder and lead-calcium alloy plate effectively lockup electricity power supply.

5) Security:

Special configuration and equipment with good anti acid-mist and anti-explosion.

6) Long service life:

Super anti-erosion material guarantees battery long service life.







3.APPLICATIONS AND MAINTENANCE:



1) It’s Sealed Valve Regulated with none requirement to add extra water or maintenance when using



2) Excellent High-Rate Discharge Performance: Being propitious to start with high current



3) Recharging: when open circuit voltage is lower than 12.6V(12V series) or 6.3V(6V series) before using



Recharging Method: Charging 4-10 hours by 0.1C10 constant current



4) Charging Voltage, when normal using, is 12.8V-14.5V(12V series) or 6.9-7.2V and Max Charging Current 0.4-0.5C10(A)



5) Application Temperature: -20-60°C



6) Not upside down when transporting, storing and using



7) Recharging: Offloading the battery to recharge when Motorcycle could not start well, poor lamp lighting and weak trumpet



8) Timely Recharging if long time no use. Normally, it’s 1-2months.



Storage place should be prevented from humidity, high temperature and avoid to keep in the place of corrosive gas and solvent.





4. FACTORY VIEWS & CERTIFICATIONS :



  Factory House:



12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5

Certification:

12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5



5.Product Catalog





12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5



Item

12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5 12N9-4B Motocycle battery

Brand Name

DENEL BRAND OR CUSTOMERS’ OEM BRAND





Verified Information
12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5 This information was Verified by 12N9-4B Good Quality Dry Charged Motorcycle Battery For Street Motorcycle SL125-5 Bureau Veritas and is valid for the following period: 2013/04/03 --- 2014/04/03
Liyang conventional N-series battery
  Model Capacity Net Weight(Kg) Longth Width Height
1 6N4-2A 4 0.53 65 18 75
2 6N4B-2A 4 0.59 100 47 96
3 6N6-3B-1 6 0.79 100 58 107
4 6N11A-1B 11 1.25 121 58 128
5 12N2.5-3C 2.5 0.7 80 70 104
6 12N4-3B 4 1.1 120 70 93
7 12N5-3B 5 1.37 120 60 130
8 12N6-3B 6 1.37 135 70 95
9 12N6.5-3A 6.5 1.55 140 69 100
10 12N6.5-3B 6.5 1.55 140 69 100
11 12N7-3A 7 1.8 135 75 130
12 12N7-3B 7 1.8 135 75 130
13 12N7-4B 7 1.8 135 75 130
14 12N7B-3A 7 1.7 150 60

130
15 12N7C-4B 7 1.83 150 85 95
16 12N9-3B 9 2.14 136 76 139
17 12N9-4B 9 2.14 136 76 739
18 12N10-3B 10   135 91 145
19 12N12-3A 12 2.8 134 81 160
20 12N12-4A 12 2.8 134 81 160
21 12N14-3A 14 3.27 133 89 163
22 12N16-3B 16   175 100 155
23 1218 18 3.6 185 125 160
24 12N28 24 4.6 185 125 160
25 6-QA-32 32   195 128 171
26 6-QA-36 30   197 128 200
27 6-QA-45 38   237 128 200
