Home > Products > Ringlock Scaffolding > Scaffolding part ringlock Scaffold aluma rosette
Scaffolding part ringlock Scaffold aluma rosette
- 100000 Piece / Pieces per Month
- QINGDAO
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | QUEEN | Model Number: | 48 |
Packaging Details
BY STEEL PALLE
Product Description
Specifications
ringlock Scaffold1) Raw materil:Q235&Q345
2)Surface finish:painted .HDG
3)Pipe:48.3*3.2mm/3.8m
Ringlock Scaffolding Systems / ringlock Scaffold
Ringlock Ledger
RINGLOCK STANDARD WITH SPIGOT(Connector) |
|
(48.3mm x 3.2mm, Q345 Material, Hot Dipped Galvanized surface finish) | |
Description | Weight |
Ring-Lock Standard 500mm | 2.76kg |
Ring-Lock Standard 1000mm | 5.18kg |
Ring-Lock Standard 1500mm | 7.61kg |
Ring-Lock Standard 2000mm | 10.03kg |
Ring-Lock Standard 2500mm | 12.45kg |
Ring-Lock Standard 3000mm | 14.87kg |
Ring-Lock Standard 4000mm | 19.72kg |
RINGLOCK LEDGER |
|
(48.3mm x 3.0mm, Q235, Hot Dipped Galvanized) |
|
Description | Weight |
Ring-Lock Ledger 1000mm | 4.62kg |
Ring-Lock Ledger 1500mm | 6.50kg |
Ring-Lock Ledger 2000mm | 8.38kg |
Ring-Lock Ledger 2500mm | 10.27kg |
Ring-Lock Ledger 3000mm | 12.16kg |
RINGLOCK DIAGONAL |
|
(48.3mm x 3.2mm, Q235, Hot Dipped Galvanized) | |
Description | Weight |
Ring-Lock Diagonal 1000x2000mm | 10.06kg |
Ring-Lock Diagonal 1500x2000mm | 10.95kg |
Ring-Lock Diagonal 2000x2000mm | 12.13kg |
Standard
Use: Standards are the vertical members of ringlock scaffolding. They provide the
vertical support for scaffolding.
ledger
Use: Ledgers are the horizontal members of Ringlock scaffolding. They provide
horizontal support for loads and planks. Ledgers can also be used as mid rail and top or hand guard rails
Base collar
Use: The base collar is designed to “base out” the Ringlock scaffolding system sitting on top of the screw jack creating a lower node point.
Feature
1. The multi-function.
2. No any active lock parts, maximum limit to prevent the traditional scaffold activities lock parts caused by unsafe hidden trouble. 3. The products have a high efficiency, the use of more convenient and faster.
4. The bearing capacity is big.
5. Safe and reliable. Strong stability. Each stud allow bearing 3-4 tons. The use of the diagonal member number is greatly less than traditional scaffolding.
6. Good comprehensive benefits. Component series of standardized, easy to transport and management. Late no scattered easily lost artifacts, low loss, less investment.
Production Workshop
Packing and the Loading Details
About us
We specialized in the filed of the hardware and scaffolding systems for10 years time and we dealing with many kinds of the Scaffolding .like Ringlock.Cuplock.Kwikstage scaffolding .frame systems. Shoring propsystems. hardware like handtools, Auto Tools. Building tools, such as the ratchet wrench.Pickaxe, Firmer chisel,shovel, pickaxe,various hammers,Triangle bricklayer,Scraper and so on. We want to emphasize that our goods get the reputation in the market due to the competitive price with the high quality. please do not hesitate to contact us meanwhile we will offer you the best with the quality you satisfied.
Company Profile
Since 2000, we has been specialized in manufacturing scaffoldings, kwik stage/ringlock/cuplock/frame scaffoldings, steel planks, couplers, accessories & formwork parts, and hardware, ratchet wrench tools, garden tools, sockets and accessories. We expand our products to hand tools, automotive tools, etc. We have more than 10 years of production and export experience. Each tool produced by Queen is in the best quality, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
We have a highly experienced producing team, which maintains top level of every stage of the producing progress. Each team of workers is led by supervisor who monitors day to day works. Automated welding and robot systems are widely used.
Today, we have customers in over 35 countries around the world. Our products are engineered for safety, strength and flexibility to meet international standards within this industry. It is important for structural engineers, scaffolding factories and formwork specialists. In terms of working processes, we have expertise in iron casting, steel forging and thread rolling. We have a complete quality control system, which guarantees the high quality of our products and makes sure all progress is made to schedule.
With all our technical knowledge and capacity, if you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
