Easy Install Steel Cuplock Scaffolding/Quick Lock System for Round Building Construction, Scaffolding Manufacturer

by steel pallet

Specifications

Cuplock Scaffolding System
1)Raw material:Q235/Q345
2)Size of pipe:48.3*3.25mm
3)Surface finish:Powder coated/galvanized/HDG

Description of Shandong supplier Q235 metal cuplock construction scaffolding.

We can supply all size and type according to your requirment and drawing.





Easy Install Steel Cuplock Scaffolding/Quick Lock System for Round Building Construction, Scaffolding Manufacturer

Feature

1. Cuplock scaffolding system has high flexibility and high loading capacity. And it is mainly used to build bridges, tunnels, metro stations, and etc.

2. Cuplock scffolding is made by Q235 steel which is strong and durable.

3. A complete cuplock scaffolding system includes standards, ledgers, or diagonal braces.

4. The accessories of cuplock scaffolding system are cantilever bracket, side bracket, ladder bracket, ladder, intermediate, and etc.
5. One standard is welded an up cup and a bottom cup in every 500mm to join ledgers at different
heights.
6. One ledger is welded a ledger blade on both ends.

Specification

Item Name	Cuplock Scaffolding
Brand Name	Queen
Raw Material	Q235 /Q345steel Grade
Components	Standard.Ledger .Diagonal brace. Top/Bottop Cup/ Ledge Blade
Surface finish	Electric Galvanized/HDG/Powder coated
Size	Pipe size:48.3mm
	Thickness:3.25mm
Usage	Widely used in Bridge .Tunnel.Peterifaction.Shipbuilding .railway,Airport. Dock Industry and Civil Building
Packing	By Steel pallet or bulk
Standard	48.3*3.25*500mm	3.5kg
	48.3*3.25*1000mm	5.6kg
	48.3*3.25*1300mm	8.0kg
	48.3*3.25*1500mm	8.75kg
	48.3*3.25*1800mm	10.6kg
	48.3*3.25*2000mm	11.4kg
	48.3*3.25*2500mm	14.0kg
	48.3*3.25*3000mm	16.70kg
	8.3*3.25*4000mm	20.36kg
Ledger	48.3*3.25*650mm	2.54kg
	48.3*3.25*914mm	3.6kg
	48.3*3.25*1065mm	4.10kg
	48.3*3.25*1150mm	4.7kg
	48.3*3.25*1570mm	5.76kg
	48.3*3.25*1829mm	6.62kg
	48.3*3.25*2130mm	7.62kg
	48.3*3.25*2438mm	8.24kg
	48.3*3.25*3050mm	10.68kg
Diagonal brace	48.3*3.25*915mm	3.4kg
	48.3*3.25*1150mm	4.04kg
	48.3*3.25*1572mm	5.34kg
	48.3*3.25*1829mm	6.13kg
	48.3*3.25*2130mm	7.06kg
	48.3*3.25*2438mm	8.01kg
	48.3*3.25*3050mm	9.90kg
Steel Plank	210*45*1.2*1000/2000/3000/4000
	250*50*1.2*1000/2000/3000/4000
Screw jack base	38*4.0*500mm	3.35kg
	38*4.0*600mm	3.65kg
	48*4.0*600mm	4.4kg
	35*500mm	4.5kg



Products   Display







Package





About us

   Our canpany was found in 1996.The workshops cover 31000 squaremeters,and we employed more than 360 well trained employees .our location is 10 minutes far away form LINYI airport, and 3 hour far away from Qingdao shipping port by car. we are a  professional manufacturer ofscaffolding ,ringlock system,cuplock system,shoring props,frame system,fences and barriers,scaffolding couplers,rapaid clamp and other related accessories.We also produce hand tools---Adjustable wrench Geartech wrench Surface rathchet Heavy duty Ratchet wrench.All of scaffolding systems produced according the standard of BS1139 and/or EN74.With strong R&D power and strict quality control system,our products passed the certification of ISO9001:2000.We provide OEM services and welcome customers‘samples and designs.



please feel free to contact if you have any question .
