Home > Products > Cuplock Scaffolding > Paint/Galvanized Cuplock Scaffolding system,construction scaffolding system,scaffold system

Paint/Galvanized Cuplock Scaffolding system,construction scaffolding system,scaffold system

Name: Paint/Galvanized Cuplock Scaffolding system,construction scaffolding system,scaffold system
Brand: QUEEN
Availability: InStock

FOB Price

US$ 2.5 - 19.5 / Set

1000 Sets(Min. Order)

Port QINGDAO
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	QUEEN
Model Number	1500

Packaging Details

by steel pallet

Product Description

Specifications

Cuplock scaffolding system
1)Raw material:Q235/Q345
2)Size of pipe:48.3*3.25mm
3)Surface finish:Powder coated/galvanized/HDG

Description of Shandong supplier Q235 painted metal cuplock construction scaffolding

We can supply all size according to your demand or drawing.

Paint/Galvanized Cuplock Scaffolding system,construction scaffolding system,scaffold system

1. Cuplock scaffolding system has high flexibility and high loading capacity. And it is mainly used to build bridges, tunnels, metro stations, and etc.

2. Cuplock scffolding is made by Q235 steel which is strong and durable.

3. A complete cuplock scaffolding system includes standards, ledgers, or diagonal braces.

4. The accessories of cuplock scaffolding system are cantilever bracket, side bracket, ladder bracket, ladder, intermediate, and etc.
5. One standard is welded an up cup and a bottom cup in every 500mm to join ledgers at different
heights.
6. One ledger is welded a ledger blade on both ends.

Specification of cuplock scaffolding

Item Name	Cuplock Scaffolding
Brand Name	Queen
Raw Material	Q235 /Q345steel Grade
Components	Standard.Ledger .Diagonal brace. Top/Bottop Cup/ Ledge Blade
Surface finish	Electric Galvanized/HDG/Powder coated
Size	Pipe size:48.3mm
	Thickness:3.25mm
Usage	Widely used in Bridge .Tunnel.Peterifaction.Shipbuilding .railway,Airport. Dock Industry and Civil Building
Packing	By Steel pallet or bulk
Standard	48.33.25500mm	3.5kg
	48.33.251000mm	5.6kg
	48.33.251300mm	8.0kg
	48.33.251500mm	8.75kg
	48.33.251800mm	10.6kg
	48.33.252000mm	11.4kg
	48.33.252500mm	14.0kg
	48.33.253000mm	16.70kg
	8.33.254000mm	20.36kg
Ledger	48.33.25650mm	2.54kg
	48.33.25914mm	3.6kg
	48.33.251065mm	4.10kg
	48.33.251150mm	4.7kg
	48.33.251570mm	5.76kg
	48.33.251829mm	6.62kg
	48.33.252130mm	7.62kg
	48.33.252438mm	8.24kg
	48.33.253050mm	10.68kg
Diagonal brace	48.33.25915mm	3.4kg
	48.33.251150mm	4.04kg
	48.33.251572mm	5.34kg
	48.33.251829mm	6.13kg
	48.33.252130mm	7.06kg
	48.33.252438mm	8.01kg
	48.33.253050mm	9.90kg
Steel Plank	210451.2*1000/2000/3000/4000
	250501.2*1000/2000/3000/4000
Screw jack base	384.0500mm	3.35kg
	384.0600mm	3.65kg
	484.0600mm	4.4kg
	35*500mm	4.5kg

Products display

Package

About us

Our canpany was found in 1996.The workshops cover 31000 squaremeters,and we employed more than 360 well trained employees .our location is 10 minutes far away form LINYI airport, and 3 hour far away from Qingdao shipping port by car. we are a professional manufacturer ofscaffolding ,ringlock system,cuplock system,shoring props,frame system,fences and barriers,scaffolding couplers,rapaid clamp and other related accessories.We also produce hand tools---Adjustable wrench Geartech wrench Surface rathchet Heavy duty Ratchet wrench.All of scaffolding systems produced according the standard of BS1139 and/or EN74.With strong R&D power and strict quality control system,our products passed the certification of ISO9001:2000.We provide OEM services and welcome customers‘samples and designs.

please feel free to contact if you have any question .

Company Profile

Linyi Queen Imp. & Exp. Co., Ltd.

Since 2000, we has been specialized in manufacturing scaffoldings, kwik stage/ringlock/cuplock/frame scaffoldings, steel planks, couplers, accessories & formwork parts, and hardware, ratchet wrench tools, garden tools, sockets and accessories. We expand our products to hand tools, automotive tools, etc. We have more than 10 years of production and export experience. Each tool produced by Queen is in the best quality, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world. We have a highly experienced producing team, which maintains top level of every stage of the producing progress. Each team of workers is led by supervisor who monitors day to day works. Automated welding and robot systems are widely used. Today, we have customers in over 35 countries around the world. Our products are engineered for safety, strength and flexibility to meet international standards within this industry. It is important for structural engineers, scaffolding factories and formwork specialists. In terms of working processes, we have expertise in iron casting, steel forging and thread rolling. We have a complete quality control system, which guarantees the high quality of our products and makes sure all progress is made to schedule. With all our technical knowledge and capacity, if you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
