Place of Origin
Zhejiang, China
Brand Name
TOPON
Model Number
TP-084
Type
Hand Tool Parts
Specifications
Tungsten carbide rod*Extruded rod,HIP sintered
*ground and blanks rod are available
*processing cast iron,alloy steel,metal
Tungsten carbide rod(extruded rod)
The following is the tolerance of the blank rod
| Dia. (mm) | Tol.Dia(mm) | Length(mm) | Tol.L (mm) |
| 2.35~6.5 | -0/+0.05 | 38.5 | +/-0.02 |
| 3.50~6.85 | +0.20/+0.40 | 12.8 | +/-0.10 |
| 3.00~12.00 | +0.20/+0.45 | 330 | -0/+0.50 |
| 12.50~20.00 | +0.20/+0.60 | 330 | -0/+0.50 |
| 21.00~30.00 | +0.20/+0.80 | 330 | -0/+0.50 |
Specifications
1.Solid tungsten carbide rod which is from diameter:0.5mm-25.4mm,330mm or cut correctly
2.ISO grade K10 /01 k 20 / k 30
