Metallurgical Steries Microscopes

FOB Price

US$ 80 - 120 / Piece

10 Pieces(Min. Order)

Port SHANGHAI
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	HG
Model Number	NF-100/102/106	Theory	Stereo Microscope
Drawtube	Other

Product Description

Specifications

WE CAN SUPPLY MICROSCOPES

Information

Metallurgical microscope is suitable for appraise and analysis the structure of various metal,alloy material and non-metal material.It is widely used in electronics industry,chemical engineering and instruments and meters to observe surface of the opaque material,chip PCB,LCD ,wire ,fiber,plating and other non-metal material.with infinitive optical system providing excellent optical functions.The instrument can also used in biological study with the incident and transmitted illumination,imaging and observing system

SPECIFICATION LIST

Components

Specification

Model

NF-100

NF-102

NF-102A

NF-106

Compensation Viewing Head

Binocular

Trinocular

Eyepiece

WF10×/18mm

WF10×/22mm

WF10×/18mm(cross scaled 0.1mm

WF8×/18mm

WF12.5×/15mm

Objective

Infinitive Plan Achromatic Objective	4×/0.1∞/-WD25.4mm
	10×/0.25∞/-WD11.0mm
	20×/0.40∞/-WD6.0mm
	40×/0.60∞/-WD3.7mm
	80×/0.90∞/-WD0.2mm
45mmDIN Achromatic objective	10×
	40×(S)
	100×(S,oil)

Nosepiece

Quadruple Nosepiece

Triple Nosepiece

Stage

Double Layers Mechanical Stage150mm×140mm,Moving range75mm×50mm

Double Layers Mechanical Stage300mm×268mm,Moving range250mm×250mm

Double Layers Mechanical Stage 150mm×140mm,Moving range70mm×50mm

Focusing

Coaxial Coarse & fine focus adjustment system

Ullumination

Halogen lamp 6v20V,Brightness adjustable

Polarization

Polarizer

Filter

blue,yellow,green,and frosted glass

Digital camera port

"C" Standard port

Image process soft ware

Standard Optional
