Name: CHAIN HOIST
Brand: kbd
SKU: 143352532
Availability: InStock

ALL CATEGORIES

CHAIN HOIST

Specifications

Rmarks:inaddition to the standard lift we accept orders to 12m lift.

Model		HSZ-B/	HSZ-B1	HSZ-B1¹/₂	HSZ-B2	HSZ-B3	HSZ-B5	HSZ-B10	HSZ-B20
Capacity (T)		0.5	1	1.5	2	3	5	10	20
Standard lifting height (m)		2.5	2.5	2.5	2.5	3	3	3	3
Test load (T)		0.75	1.5	2.25	3.0	4.5	6.25	12.5	25
Headroom (drawn colse up) Hmin (mm)		271	400	453	420	620	704	720	1000
Chainpull to lift full load (N)		221	304	343	314	343	382	392	392
No.of load chain fall lines		1	1	1	2	2	2	4	8
Diameter of bad chain (mm)		6	6	8	6	8	10	10	10
Dimensions (mm)	A	138	164	198	164	198	228	367	598
	B	114	124	142	124	142	167	167	200
	C	21.5	27	30	30	37	46	54	65
	D	145	182	219	182	219	252	252	252
Net weight (Kg)		9	11	17	15	24	39	72	160
Gross Weight (Kg)		11	14	21	18	28	48	87	190
Packing mcasurement (LWaH) cm		28x21x17	30x24x18	34x29x21	33x28x19	38x33x20	45x39x24	55x51x29	70x46x75
Extra weight per meter of extra lift (Kg)		1.7	1.7	2.3	2.5	3.7	5.3	9.7	19.4
