Multi-function Processing Calibrator

US$ 650 - 750 MOQ: 5 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

MS7212

KBD Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name MS

Model Number MS7212

Specifications

High quality multi-function processing calibrator can be supplied to our customers

FEATURES

	Measure V, mA, Ω, frequency, temperature, 40000 reading max
	Source V, mA, frequency, high resolution, voltage and current is scale up in 0 to 99 steps, and output echelon voltage and current
	With PC photoelectricity interface, transfer the results to a PC, save and print transfered data and data waveform in special software
	With measure and source two functions, show and control in double display
	32 function keys and numeric keys, setup and modify source value by numeric keys in source mode Output power: 15V 25mA

SPECIFICATIONS

Measure (DMM)
Range (full scale)	Accuracy (% of reading + digits)
400.00mV DC 4.0000V DC 40.000V DC 300.00V DC 400.00mV 4.0000V AC 40.000V AC 300.00V AC 400.00mA DC 400.00mA AC 400.00Ω 4.0000kΩ 40.000kΩ 400.00kΩ 4Hz ~ 99.99Hz 100Hz ~ 5Hz 5kHz ~ 30kHz -50°C ~ 1300°C	0.025% + 10 0.025% + 5 0.025% + 5 0.025% + 5 0.7% + 20 0.7% + 10 0.7% + 10 0.7% + 10 0.1% + 10 0.7% + 10 0.1% + 10 0.1% + 10 0.1% + 10 0.1% + 10 0.05Hz 0.5Hz 2Hz 0.3% + 1°C

Source
Range (full scale)	Accuracy (% of reading + % of full scale)
100.000mV DC 5.0000V DC 15.000V DC 25.000mA 20Hz ~ 5000Hz	0.025% + 0.03% 0.025% + 0.02% 0.025% + 0.02% 0.02% + 0.02% 0.02%
