Lamination Machine, Laminator ADL-1600H1
- 1000 Set / Sets per Month
- any port
- Credit Card
- UGS1007 double side seven colors automatic Cloth trademark printer, garment label rotary printing machine price
- ZXJR 1262 label printing machine
- ZXJR1221 label offset printing machine
- Four-Color Double-side High-speed Rotational Belt Printer
- MY-380F Hualian Solid-Ink Coding Machine
- MY-420A HUALIAN New Printer Machine
Product Details
Condition: | New | Plate Type: | Flatbed Printer | Place of Origin: | Henan, China |
Brand Name: | Audley | Model Number: | ADL-1600H1 | Usage: | Other, laminator |
Automatic Grade: | Automatic | Voltage: | 220V | Gross Power: | 2200W |
Weight: | 180KG | Certification: | CE |
Product Description
Lamination Machine, Laminator ADL-1600H1:
Max width | 1600mm |
Max thickness | 20mm |
Speed | 0---7m/min |
Temper range | Room temp-120`c |
Lifting way | Unilateral ascension |
Heating way | Infrared heating |
Preheating time | 10-15min |
Rated input power | 2200w |
Power | 0.8-1kw/h |
Rated input voltage | 110/220v |
Weight | 230/180kg |
Packing size | 220*71*80cm |
Auto | yes |
Configuration:
1. Motor
2. Turn-over aluminium alloy front working platform.
3. 130mm-diameter high-temperature resisting silica gel upper-roller.
4. 130mm- diameter anti-adhesive silica gel lower-roller .
5. Automatic product rolling structure.
6. Crikle-resistant and anti-slided paper advancing structure.
7. Unilateral balanced voltage controlled hand wheel.
8. Non-contact infrared temp-measuring system.
9. Pedal switch
Features:
(1) Reduce the cost, improve quality.
Each square directly reduce cost for 1.5 yuan
Good color reductibility, high transparency,no air bubbles ,no snow point phenomenon
(2) High efficiency coated film, high yield.
Coated the whole volume 50 m, don't walk inclined
Can realize single or unmanned operation, 220 square/hour
Thin back glue not wrinkle, brunet picture of the prison coated film.
(3) Can be used for low heating cold lamination
50 degrees cold framed can completely avoid bubble, snow point phenomenon
Automatic open under paper function
Can realize single or unmanned 400 square/hour
(4) application scope
Indoor and outdoor car stick, photo and video
