Audley single side electric hot laminator 1600 ,1600 hot laminator-H1
reduce the cost, improve quality
Hot & cold laminating
Indoor and outdoor car sticker, photo and graphic images
Model |
1600H1(single-sided) |
Max Width |
1520mm |
Max Thickness |
20mm |
Speed |
0--7m/min |
Temp Range |
room temp-120°C |
Lifting Way |
unilateral ascension |
Heating Way |
infrared heating |
Preheating Time |
10-15min |
Rated Input Power |
2200w |
Power |
0.8-1kw/h |
Rated Input Voltage |
110/220v |
Weight |
230/180kg |
Packing Size |
220*71*80cm |
Machine Configuration | ||||||||||||||||||||||||||||||||||||
1.60W retarding moment motor | ||||||||||||||||||||||||||||||||||||
2.Turn-over aluminium alloy front working platform | ||||||||||||||||||||||||||||||||||||
3.130MM-diameter high-temperature resisting silica gel upper-roller | ||||||||||||||||||||||||||||||||||||
|
4.130MM-diameter anti-ad reduce the cost, improve quality
hesive silica gel lower-roller | ||||||||||||||||||||||||||||||||||||
5.Automatic product rolling structure | ||||||||||||||||||||||||||||||||||||
6.Crinkle-resistant and anti-slided paper advancing structure(initiative) | ||||||||||||||||||||||||||||||||||||
7.Unilateral balanced voltage controlled hand wheel | ||||||||||||||||||||||||||||||||||||
8.Non-contact infrared temp-measuring system | ||||||||||||||||||||||||||||||||||||
9.Pedal switch |
