Steadily pressure system accurate semi-auto hot and cold lamination machine

FOB Price

US$ 1,800 - 2,200 / Unit

1 Unit(Min. Order)

Port Ningbo or Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Packaging Type	Film	Packaging Material	Paper, Other, Paper, All inkjet and pinting materials
Automatic Grade	Semi-Automatic	Driven Type	Electric
Voltage	110V / 220V	Power	2200W
Place of Origin	Zhejiang, China	Brand Name	OEM
Model Number	F-1700F1	Dimension(LWH)	Inquire
Weight	Inquire	Certification	CE, RCM, ROHS
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

******The pricture and specifications are subject to change without prior notice. ******

******Any question, please confirm with our sales manager.******

Welcome to Boway

Core Competence

We provide more than 300 kinds of office equipment for your need

(You may click the following picture to see more)

How to Choose Your Right Items?

Product Uses

F-1700F1 semi-auto hot and cold laminator satisfies applications that need lamination width no more than 1620mm/64''.

It is an ideal film laminator for sign and graphic makers. It is extremely cost-efficient for common applications.

Appearance

Specification Param

Model	F-1700F1
Type	Hot and Cold
Max. Lamination Width	1620mm / 64 ''
Max. Lamination Thickness	Up to 23mm / 0.9 ''
Heating	Infrared
Heating Type	Heated top roller
Max. Temp.	120 °C / 248 °F
Warm Up Time	10-15 min
Max. Speed	Up to 7m/min
Roller	Silicon
Roller Diameter	130mm / 5''
Power	2200W
Voltage	110V / 220V
Height Adjustment	Hand Crank
Pressure Adjustment	Hand Crank
Foot Pedal Switch	Yes
Safety	Laser eye
Certificate	CE, RCM, ROHS
Static-free	Yes

Advantages Details

Designed with stronger frame, large diameter silicon rollers, steadily pressure system etc., the semi-auto hot and cold laminator offers more accurate
application than ever. While using, safety with laser eye and emergency device provides dual protection for operators. Simultaneously, the new even lighter self-blocking roll-shafts configured make operators easily, quickly change films. More time will be saved. Our semi-automatic film laminating machinery of F-1700F1 series is really a good helper for your work.

Optimum Performance
1. F-1700F1 cold and hot laminator provides better application with high quality rollers.
2. Its settings are adjustable, increasing capacity and versatility.
3. The processing speeds are up to 7m/min, which is really so fast.
4. The laminating machine comes with unique anti-tilt and anti-fold system for ensuing clear output.
5. It is suitable for hot and cold laminations.

Ease of Use
1. Our hot and cold laminating machine is easily cleaned because of its high release silicone rollers.
2. Through a simple adjustment knob, the materials tension can be adjusted.
3. Light weight drop-in supply shafts with auto-grip are designed for easy loading
4. The hot and cold laminating machinery allows for roll-to-roll application.

Safety
1. Our cold and hot laminator has foot switch for hands free operation.
2. Laser safety eyes and 2 emergency stops provide dual protections for operators.
3. All cold and hot laminating machines are CE, RCM, and ROHS approved.

Package & Shipment

Trading Terms

Terms of payment	T/T, L/C, Westion Union.
Terms of trade	FOB, CFR, CIF
Mode of transportation	By Sea, By Air
Port of shipment	Shanghai or Ningbo
Rerfence date of delivery	About 15 days, Instant supply of hot-selling products

About Shipment

Certificate of Fumigation	√
Certificate of Original	CO, FORM A, FORM F, FORM E etc. Guarantee customer to import goods at the preferential tariff rate
Certificate of Inspection	√
Documents Authentication	√

After-Sales Service

I. Agents Tranining

II. Warranty

We provide one-year limited warranty for all machines from the date of purchase

1. Our warranty covers only those defects which arise as a result of normal use of the product, and the bellows not apply to any:

u Improper or inadequate maintenance

u Misusage and mishandling

u Damaged by a wrong voltage use

u Physical damage(for example, dropping the parts on the floor or into water, broken case, etc)

2. What is the repair, exchange & refund policy?

Exchange and refund only on big defective units (beyond repair).For buyers' used machines, we only can support repair service.

Repair: We provide free spare parts (just include the main board and motor) within the warranty period. Buyer should provide serial number and photos of defective machines, but buyer should pay the shipment charges and return us the broken parts.

Exchange: If you reported problem to us in one month on arrival of the machine, we accept the exchange. Buyer needs pay the ship back sea freight and the sea freight for new machine.

Refund: If you reported problem to us in one week on arrival of machines, we accept the refund, but we only refund you the payment after receiving the returned goods.

3. What about when one year warranty over time?

We still offer the repair service to you when the warranty time is over, even we can offer you the repair service in the whole life of machine.

4. How to support you when you purchase our machine in first time?

When you meet the problem of our machine under the situation that you are not familiar with our machines.

Do not worry, we can offer:

u User Manual in English

u Operation Video

u Support on-line

u You can send your technician to our factory to attend the skill training.

Customers and Us

FAQ

1.What’s the product range?

Post press machine,such as Perfect glue binder, paper cutter, Roll laminator, UV coator machine and some small office equipment.

2.Are you a manufacture?

Yes, we are in Hangzhou which middle of shanghai and Ningbo

3.What is the minimum quantity for order?

5 pcs or 10000 USD for order.

4.Do you have stock product to sell?

Maybe , It’s depend on which machine ,you like?

5.Do you inspect the finished products?

Yes, Each step of production products will be camed out inspection by QC department before shipping.

6.How do you ship the finished products?

By Sea

By Plane

By courier, TNT , DHL, Fedex, UPS Etc

7.What’s the Payment term?

Payment term: T/T before shipment.

We accept payment via the Paypal /Western union/TT, you can choose as you like.

8.What’s the delivery time?

Within 15 days after get the payment
