Polyester Resin for Hybrid Power Coating

Name: Polyester Resin for Hybrid Power Coating
Brand: Huahai
SKU: 143336226

Negotiable MOQ: 10 Metric Tons (Price negotiable depending on order volume and customization)

Key Specifications

CAS No.:

not have

Place of Origin:

Shandong, China

Type:

Synthetic Resin and Plastics

Tengzhou City Huahai New Thermal Insulation Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

CAS No. not have

Place of Origin Shandong, China

Type Synthetic Resin and Plastics

Brand Name Huahai

Model Number Huaguan7030

Specifications

Polyester resin
1.Only suitable for use with powder coating.
2.With excellent flow
3.High weathering resistance

Polyester Resin for hybrid Power Coating

Application	P7030 polyester resin is a kind of saturated carboxyl polyester resin mixed with epoxy resin in 70/30 for epoxy/polyester powder coatings.
Properties	Very high gloss Good flow Good mechanical properties Perfect anti-yellowing Good storage stability
Specfications	Appearance Chip solid Color(50%DMF) max 4 Acid Value,mg KON/g 28-34 Softening Point(ball)°C 95-115 Tg,°C ≥ Min.50
Package and Shelf life	25kg net in polyethylene bag, one year in a dry and well-ventilated place at temperature below 30°C.
Recommended Formulation	P7030 420g Epoxy Resin(E-12) 180g TiO2 300g Flow Agent(SF-2) 50g Benzoin 5g
Extrusion Condition	Extruder BUSS PLK46 Casing setting temp°C 110-120 Kneading screw temp.,°C 70 R.P.M 50 Particle size μm,max 100 Curing Condition 180°C×15min (MT)
Film Properties	Thickness μm 60+/-10 Gloss,60°(%),≥90 Cross-hatch adhision(2mm) 0-1 Belting,mm,min≤6 Slow penetration.mm.max ≥7 Impact,Kg.c 50 Hardness(pencil),H 1-2
Application Condition	Spraying tension, KV 60 Degreased cold-rolled steel,mm 0.5
